Page 1 Document 95895 L180 Tape Library Operator’s Guide...
Page 3 L180 Tape Library Operator’s Guide...
Page 4 Copyright Statement: (c) 1999, 2003 Storage Technology Corporation. All rights reserved. StorageTek and the StorageTek logo are trademarks or registered trademarks of Storage Technology Corporation. Other products and names mentioned herein are for identification purposes only and may be trademarks of their respective companies.
Page 5: Summary Of Changes
Summary of Changes Date Edition Description 111222 November 1999 First Initial release. 111426 March 2000 Second Refer to this edition for a description of the changes. 111569 November 2000 Third Refer to this edition for a description of the changes. 111640 April 2001 Fourth...
Page 6 Summary of Changes This page intentionally left blank. Ninth Edition 95895...
Page 7: Table Of Contents
StorageTek’s External Web Site ........
Page 8: Contents
Contents Storage Cells ........... . 1-5 Cell Locations .
Page 9 Contents Monitoring Status Information ......... 2-16 CAP Status .
Page 10 StorageTek’s Worldwide Offices ........
Page 11 Contents Cartridge Access Port (CAP) Usage ........B-4 PUT Count .
Page 12: Figures
Figures Figure 1-1. L180 Tape Library Major Components ....... 1-2 Figure 1-2.
Page 13 Figures Figure 3-14. Mounting a Cartridge into the T9840 Drive ......3-25 Figure 3-15. Mounting a Cartridge into an Ultrium Drive ......3-27 Figure A-1.
Page 14 Table 3-1. L180 Library Drive Diagnostic Tests ....... . 3-33...
Page 15: Preface
Preface This guide describes how to operate the StorageTek L180 Tape Library (also referred to in this guide as the L180 library, tape library, or simply just library). Most of the information pertains to library hardware, refer to your appropriate tape drive or software documentation for specific information about the drives or client software commands and console messages.
Page 16: Alert Messages
Alert Messages Alert Messages Alert messages call the reader’s attention to information that is especially important or that has a unique relationship to the main text or graphic. Note: A note provides additional information that is of special interest. A note might point out exceptions to rules or procedures.
Page 17: Related Publications
Blue (prints black in hardcopy publications) Related Publications You can find additional information in the following publications: APC Power Supply Publications Part Number L180 and L700 Tape Library 96047 Uninterruptible Power Supply Reference Manual Uninterruptible Power Supply online information Go to www.apc.com...
Page 18: Additional Information
The URL for the StorageTek external Web site is http://www.storagetek.com Customer Resource Center StorageTek’s CRC is a Web site that enables members to resolve technical issues by searching code fixes and technical documentation. CRC membership entitles you to other proactive services, such as HIPER subscriptions, technical tips, answers to frequently asked questions, addenda to product documentation books, and online product support contact information.
Page 19: Safety
L180 Door Interlock Safety Please read and observe the following safety topics for this product. L180 Door Interlock A safety interlock for the tape library is located behind the front door. When this door is opened, the interlock immediately disables all tape library motors.
Page 20: Fiber-Optic Safety
Class 1 Laser Product. Each laser transceiver has an output of less than 70 µW and a wavelength of 850 nm. StorageTek’s Class 1 Laser Products comply with EN60825-1(+A-11) and with sections 21 CFR 1040.10 and 1040.11 of the Food and Drug Administration (FDA) regulations.
Page 21: Fiber-Optic Cable Installation
• Do not coil the cable to less than 96 mm (3.75 in.) in diameter. • Do not bend the cable to less than 12 mm (0.5 in.) in radius. StorageTek recommends that a cable’s bend radius be no less than 20 times the diameter of the cable.
Page 22: Rack Safety And Precautions
Rack Safety and Precautions • Do not grasp the cables with pliers, grippers, or side cutters; do not attach pulling devices to the cables or connectors. • Keep cables away from sharp edges or sharp protrusions that could cut or wear through the cable;...
Page 23 • Install the equipment from the bottom of the rack to the top of the rack; StorageTek recommends that you place the heaviest items near the bottom of the rack. • Ensure that the equipment in the rack does not create an overcurrent condition, whether equipment is connected directly to the branch circuit or to a power distribution strip.
Page 24 Rack Safety and Precautions L180, Recommendations for Equipment Rated to 35 C (89.6 F) May Exceed Operating Temperatures Fan Recommended No Fan Needed (59 F) Rack Equipment Power (Watts) L180, Recommendations for Equipment Rated to 40 C (89.6 F) May Exceed Operating Temperatures...
Page 25: Notices
TV reception. Changes or modifications to this equipment that are not expressly approved in advance by StorageTek will void the warranty. In addition, changes or modifications to this equipment might cause it to create harmful interference.
Page 26: Japanese Compliance Statement
Japanese Compliance Statement Japanese Compliance Statement The following compliance statement in Japanese pertains to VCCI EMI regulations: English translation: This is a Class A product based on the standard of the Voluntary Control Council for Interference by Information Technology Equipment (VCCI). If this equipment is used in a domestic environment, radio disturbance may occur, in which case, the user may be required to take corrective actions.
Page 27: Internal Code License Statement
YOU DO NOT HAVE THE AUTHORITY TO BIND YOUR COMPANY, DO NOT OPEN THE PACKAGE AND USE THE EQUIPMENT. IF YOU HAVE ANY QUESTIONS, CONTACT THE AUTHORIZED STORAGETEK DISTRIBUTOR OR RESELLER FROM WHOM YOU ACQUIRED THIS EQUIPMENT. IF THE EQUIPMENT WAS OBTAINED BY YOU DIRECTLY FROM STORAGETEK, CONTACT YOUR STORAGETEK REPRESENTATIVE.
Page 28 Code, service tools and manuals being reserved by Code and Maintenance Code may reside and be StorageTek or its licensors. You agree that you shall executed in or used in connection with such not use or attempt to use the Maintenance Code or...
Page 29: 1: General Information
General Information This chapter describes the components of the L180 Tape Library. The library is the hardware component in an automated cartridge system. More specifically, the library is a robotic system that stores, moves, mounts, and dismounts tape cartridges that are used for data read or write operations.
Page 30: Figure 1-1. L180 Tape Library Major Components
Library Components Figure 1-1. L180 Tape Library Major Components (C67036) C67036 1. Rear door 2. Rack door 3. Operator panel 4. Front door 5. Cartridge access port (CAP) 6. Robotics 7. Arrays 8. Drives Ninth Edition 95895...
Page 31: Robot
Library Components Robot Figure 1-2 shows the components of the robot: • Theta motor (controls lateral movement) • Z column motor (controls vertical movement) • Hand-camera assembly on the Z carriage (controls cartridge movement to and from the cells, the drives, and the CAP) The robot: •...
Page 32: Hand-Camera Assembly
Library Components Hand-Camera Assembly Figure 1-3 shows the hand-camera assembly which consists of a gripper, a motor-driven drive belt for gripper extension, and a bar code scanner card and camera (enclosed in a case under the hand components). The camera reads the volume serial numbers (VOLSERs) from the cartridge labels during an audit and as you enter cartridges through the CAP.
Page 33: Storage Cells
Library Components Storage Cells The storage cells (or arrays) are stacked in columns; the columns are arranged in a semicircle around the robot. Each column holds 28 cartridges. Note: Each array holds six cartridges but the top two cells in each column are not available.
Page 34: Figure 1-4. Locating Cartridges-Panels, Cells, Rows
Library Components Figure 1-4. Locating Cartridges—Panels, Cells, Rows (C67003) PANEL 1 COLUMN COLUMNS COLUMN ROWS C67003 1. 84-cartridge-cell configuration 2. 140-cartridge-cell configuration 3. 174-cartridge-cell configuration 4. Cartridge access port (CAP) 5. Reserved cell array 6. Blocked storage cells (no cartridges permitted) 7.
Page 35: Figure 1-5. Locating Cartridges-Hexadecimal
Library Components Figure 1-5. Locating Cartridges—Hexadecimal (C67004) PANEL 1 PANEL 0 PANEL 2 404h 43Ch 458h 474h 3E8h 420h 1028d 1084d 1112d 1000d 1056d 1140d 490h 1168d 41Fh 43Bh 457h 473h 48Fh 495h 403h 1055d 1083d 1111d 1139d 1167d 1173d 1027d C67004 1.
Page 36: Library Capacity
Library Components Library Capacity Table 1-1 lists library storage capacities: Table 1-1. L180 Library Capacity Model Capacity Description L180-80 84 data cartridge slots, 6 reserved cartridge slots, one DC power supply, one AC PDU L180-140 140 data cartridge slots, 6 reserved cartridge...
Page 37: Tape Drives
1.The StorageTek T9840B drive is available for ESCON operation; library firmware must be version 3.01 or later.
Page 38: Escon
Library Components Table 1-2 lists the number of each type of drive when mixing drives. Table 1-2. Mixed Drive Combinations T9840 DLT or LTO ESCON ESCON operation is now available for the T9840B drive only; it requires certain considerations that must be taken into account for correct operation. •...
Page 39: Rack Area
Library Components Rack Area The library has a six unit (U) rack area above the front door where additional equipment can be placed, including: • Servers • Fibre Channel components for a storage area network (SAN) • Uninterruptible power supply (an optional feature) CAUTION: Potential damage to library electronics and drives: The two perforated sections in the rear of the rack area provide ventilation for the library...
Page 40: Power System
Figure 1-6. Uninterruptible Power Supply (C67327) C67327 1. Power strip 2. Switch 3. Batteries Note: Refer to the L180 and L700 Tape Library Uninterruptible Power Supply Reference Manual for more information. 1-12 Ninth Edition 95895...
Page 41: Library Safety Features
Library Safety Features Library Safety Features Safety features are incorporated into the library include: • An electronic interlock to remove power from the robot if the front door to the library is opened. • Protective covers in the electronics compartment that cover the logic card, the AC power supply, and the DC power supply to prevent you from coming into contact with hazardous voltages and sensitive electronics.
Page 42: Controlling Software
Note: Refer to your software publications for command descriptions. L-Series Library Admin StorageTek’s L-Series Library Admin is an optional web-based interface to the library. If your library has this feature installed, you can perform these tasks through a workstation or PC that is running a Netscape or Microsoft browser.
Page 43: 2: Controls And Indicators
Controls and Indicators This chapter identifies and describes the functions of the L180 Tape Library operator panel and lists tasks the operator can perform through the panel. Figure 2-1 on page 2-2 shows an example of the operator panel. Operator Panel The operator panel is recessed into the library’s rack door and contains buttons,...
Page 44: Figure 2-1. Operator Panel Display, Controls, And Indicators
Operator Panel Figure 2-1. Operator Panel Display, Controls, and Indicators (C67005) C67005 1. Service Required indicator is steadily red when human intervention is required and flashes if a fan is defective. 2. Library Active indicator flashes green when the library is operational. 3.
Page 45: Display Screens
The following information are examples of these screens. Initial Status The Initial Status screen is the first screen that appears on the operator panel after an IPL. Information includes: STK L180 Code Version Version of microcode installed CAP Closed Status of the cartridge access port (CAP)
Page 46: Main Menu
Display Screens Figure 2-2. Initial Status Screen STK L180 (Code VER X.XX.XX) CAP CLOSED LIBRARY ONLINE NO REMOTE USERS COLUMN 0 00 BUSY 01 BUSY 02 --- 03 LOADING 04 EMPTY 05 EMPTY 06 EMPTY 07 --- 08 --- 09 --- C67314 1.
Page 47: Fsc Log
Display Screens FSC Log The fault symptom code (FSC) Log displays the last 20 events and includes an FSC, the number of occurrences, and the date and time of the last occurrence. “Reviewing the FSC Log” on page 3-31 for more information. The following statements apply to the FSC Log screen: •...
Page 48: Cap Contents
(also referred to as the MPC or MPCL card). Figure 2-6. Version Information VERSION INFO MENU: STK L180 CODE VERSION: x.xx.xx CODE BUILT ON:...
Page 49: Drive Information
Display Screens Drive Information The Drive Information Menu is an information-only screen that lists information about the selected drive, such as: Vendor The manufacturer of the drive Type The drive model Status The drive’s logical number and status (see “Drive Status”...
Page 50: Cleaning Information
Display Screens Cleaning Information The Cleaning Info screen provides information about and control of the library’s cleaning cartridges. Figure 2-8. Cleaning Information CLEANING INFO NUM CLEAN CARTRIDGES: 00 DLT WARN COUNT: 000 T9840 WARN COUNT: 000 HP LTO WARN COUNT: 000 IBM LTO WARN COUNT: 000 SGT LTO WARN COUNT: 000 EXPORT CARTRIDGES...
Page 51: Diagnostics
Display Screens The menu lets you change the warning count for each type of cleaning cartridge as well as import cleaning cartridges to the library and export them from the library. This menu also lets you check the number of times a cleaning cartridge has been used.
Page 52: Main Configuration Menu
Main Configuration Menu Main Configuration Menu The Main Configuration Menu routes you to the configuration menus (library, drive, network) and to the panel display controls. This menu also routes you to screens that let you view the library personality and input a password for a web interface product.
Page 53: Library Scsi Interface Configuration
Main Configuration Menu Library SCSI Interface Configuration The Lib SCSI I/F Config Menu lets you view the library’s SCSI type (differential or single-ended) and access an edit menu for the library’s SCSI ID. Figure 2-12. Library SCSI Interface Configuration Menu LIB SCSI I/F CONFIG MENU: LIB SCSI I/F ID: 00 SCSI TYPE: LVD (or HVD)
Page 54: Drive Configuration
Main Configuration Menu Drive Configuration The Drive Configuration Menu lets you modify portions of each SCSI drive’s configuration. For each drive, the menu displays the drive position, drive type, and, if the drive path is SCSI, the drive’s SCSI ID and the drive’s SCSI bus relationship with the library.
Page 55: Network Configuration
Main Configuration Menu Network Configuration The Network Config Menu lets you modify the library’s network configuration and view the library’s Ethernet address. Figure 2-15. Network Configuration Menu NETWORK CONFIG MENU: LIBRARY NAME: IP ADDRESS: 000.000.000.000 NETWORK GATEWAY: NOT SET SUBNET MASK: 000.000.000.000 DNS CONFIGURATION SVR PRIMARY...
Page 56: Display Information
Main Configuration Menu Note: This feature also requires corresponding drive code that supports the dynamic Worldwide Name feature. Currently, IBM LTO drive code 27Q1 is the only available supporting microcode. Microcode for other drives is in process and will be released with the next drive firmware versions.
Page 57: Personality Module
RESENT ORMAL ERSION IBRARY ENDOR IBRARY ENDOR IBRARY RODUCT L180 (DOWN FOR MORE INFORMATION) When you use the down arrow, additional information will appear: Figure 2-18. Personality Module Information (2 of 2) ERSONALITY ODULE LIBRARY ADMIN: ENABLED SCSI VENDOR NAME...
Page 58: Monitoring Status Information
MENU viewing the Main Menu. Figure 2-19. Example of the Initial Status Screen (C67314) STK L180 (CODE VER 3.02.00)* CAP CLOSED LIBRARY READY WEB ENABLED COLUMN 0 00 BUSY...
Page 59: Cap Status
Monitoring Status Information CAP Status The first line of status information on the initial status screen indicates the condition of the CAP. Table 2-1. CAP Status Messages Status Message Explanation The CAP door is currently open. You may insert or OPEN remove cartridges or the magazines.
Page 60: Library Status
Monitoring Status Information Library Status The following library status messages might appear: Table 2-3. Library Status Messages Status Message Explanation The library’s front door is open. When you LIB MAIN DOOR OPEN close it, the library will reinitialize. The library requires initialization. This LIB INIT REQUIRED message might appear momentarily after you close the library’s front door.
Page 61: Drive Status
Monitoring Status Information Drive Status The following drive status messages might appear: Table 2-4. Drive Status Messages Status Message Explanation You must initialize this drive. INIT REQUIRED This drive is not connected to the library. NOT CONNECTED The library does not recognize this type of drive. UNKNOWN DRIVE This drive is not communicating with the library.
Page 62: Library Personality Information
Monitoring Status Information Library Personality Information Viewing library personality information lets you determine who the library’s manufacturer is, whether a personality module is present and enabled, and how the library’s name and vendor name appear on a SCSI interface. To view the library’s personality information: 1.
Page 63 Monitoring Status Information Status Message Explanation This is the version number for the personality module. If a VERSION: personality module is not present, this is the version of the vendor information. This is the identity number for the library vendor. LIBRARY VENDOR ID: This is the name of the library vendor.
Page 64 Monitoring Status Information This page intentionally left blank. 2-22 Ninth Edition 95895...
Page 65: Library Operation
Library Operation This chapter contains procedures for the L180 Tape Library, including: • “Powering-on the Library” “Powering-off the Library” on page 3-2 • “Initializing and IPLing the Library” on page 3-4 • “Inserting Cartridges Through the CAP” on page 3-5 •...
Page 66: Powering-On The Library
Powering-on the Library Powering-on the Library Figure 3-1 on page 3-3 shows the location of the library power switch. The power switch is one or two circuit breakers behind the rear door of the library (left of the drive column). The power switch has two configurations: •...
Page 67: Figure 3-1. Library Power Switch Location
Powering-off the Library Figure 3-1. Library Power Switch Location (C67009) C67009 95895 Ninth Edition...
Page 68: Initializing And Ipling The Library
Initializing and IPLing the Library Initializing and IPLing the Library Powering-on the library causes it to initialize components and perform an IPL (initial program load). During initialization, the library prepares the robotics for use and audits any cartridges in the storage and reserved cells. During an IPL, the library loads the operating code and automatically verifies some configuration values, such as drive locations and drive types.
Page 69: Inserting Cartridges Through The Cap
Inserting Cartridges Through the CAP Inserting Cartridges Through the CAP To unlock the CAP, open it, and place cartridges into it: 1. Enter the console command to unlock the CAP. 2. Press the button on the operator panel to open the CAP. The Open indicator will light.
Page 70: Figure 3-3. Entering Dlt And T9840 Cartridges Into The Cap Magazine
Inserting Cartridges Through the CAP Figure 3-3. Entering DLT and T9840 Cartridges into the CAP Magazine (C67011) C67011 1. DLT cartridge 2. T9840 cartridge Figure 3-4. Entering Ultrium Cartridges into the CAP Magazine (C67286) C67286 Ninth Edition 95895...
Page 71: Entering Unlabeled Cartridges
Inserting Cartridges Through the CAP Entering Unlabeled Cartridges Note: StorageTek strongly advises that you do not enter unlabeled cartridges. The client software determines what happens when you enter a cartridge with a missing or unreadable label. Under ordinary conditions, the camera on the hand audits the CAP and recognizes that a cartridge is present, but the hand does not move it.
Page 72: Removing Cartridges From The Cap
Removing Cartridges From the CAP Removing Cartridges From the CAP To unlock the CAP, open the CAP, and remove cartridges from it: 1. At the system console, enter the VOLSERs of the cartridges you require. The robot will retrieve the cartridges and insert them into the CAP. 2.
Page 73 Importing Cleaning Cartridges Through the CAP 4. Press the arrow buttons until the cursor underscores IMPORT CARTRIDGES. SELECT 5. Press the button. SELECT The Import Clean Cartridges screen L E ANING NF O E NU appears, which lists all reserved cell L E AN AR T R IDGE S : cleaning cartridges by domain (or drive...
Page 74: Exporting Cleaning Cartridges Through The Cap
Exporting Cleaning Cartridges Through the CAP Exporting Cleaning Cartridges Through the CAP When one or more cleaning cartridges have expired, you can export them from the reserved cells to the CAP with this procedure: 1. Press the button to return the MENU display to the Main Menu.
Page 75 Exporting Cleaning Cartridges Through the CAP 6. Select the cleaning cartridges you want to export by: SELECT SELECT a. Moving the cursor to the desired cartridge entry on the list XPOR T LE AN AR TR IDGE S : b. Pressing the button.
Page 76: Setting The Cleaning Cartridge Warning Count
Setting the Cleaning Cartridge Warning Count Setting the Cleaning Cartridge Warning Count Cleaning cartridges have a limited life span. After multiple uses, a cleaning cartridge must be replaced and disposed of at your site. Keeping the tape drives clean is important for proper operation. You will need to clean the drives occasionally to prevent read/write errors.
Page 77: Cleaning A Drive
Cleaning a Drive 8. When you are finished, press the button twice to return to the library MENU status screen. Cleaning a Drive If you do not have the Auto Clean feature enabled, then when the library status screen displays CLEAN NEEDED you will need to manually clean the drive. To clean the drive: 1.
Page 78: Cleaning Cartridge Requirements
Cleaning a Drive The Auto Clean feature is automatically enabled if you load even one cleaning cartridge into the reserved cell area and then reset the library. Cleaning Cartridge Requirements Valid cleaning cartridges are those that match the drive types installed in the library.
Page 79: Cleaning Cartridge Expiration
You can determine if a cleaning cartridge is expired by: 1. Viewing its usage from the Cleaning Information menu 2. Viewing its usage through the StorageTek L-Series Library Admin screen 3. Observing that an asterisk (*) appears on the operator panel display; for example, STK L180 (Code 3.00.13)*...
Page 80: Opening The Front Door
Opening the Front Door Opening the Front Door CAUTION: Confined space: While reaching inside the library, take care to avoid bumping your head or catching your clothing on protruding edges. You must open the front door to perform manual operations. 1.
Page 81: Moving The Robot
Moving the Robot Moving the Robot After you open the library door, you might need to move the robot so that you can more easily access cartridges or the drives. Read and observe the following caution before you attempt to move any portion of the robot. CAUTION: Potential equipment damage: Make sure the gripper mechanism on the hand is fully retracted to prevent damaging the hand-camera assembly...
Page 82: Rotating The Z Column
Moving the Robot Rotating the Z Column If you need to rotate the Z column, grasp it and carefully rotate it. CAUTION: Potential equipment damage: Move the Z column and Z carriage only as shown in Figure 3-8, do not force the movement of the Z column. The Z column does not rotate a full 360 degrees.
Page 83: Removing A Cartridge From The Hand
Removing a Cartridge from the Hand Removing a Cartridge from the Hand If the library (control path) goes offline or experiences mechanical difficulties, a cartridge might remain in the hand. You can remove it from the hand and manually mount it into a drive for a read/write operation. CAUTION: Potential equipment damage: Follow the procedures described in “Moving the Robot”...
Page 84: Figure 3-10. Removing A Cartridge From The Hand
Removing a Cartridge from the Hand Figure 3-10. Removing a Cartridge from the Hand (C67018) C67018 3. Hold the solenoid on top of the reach mechanism with one hand and grasp the cartridge with the other. 4. Rotate the solenoid switch clockwise until the cartridge is released from the gripper, as shown in Figure 3-10.
Page 85: Locating A Cartridge In The Storage Cells
Locating a Cartridge in the Storage Cells Locating a Cartridge in the Storage Cells Figure 3-11 show the locations of the panels, rows, and columns for the storage cells. A decal at the top of each column also provides this information. To remove a cartridge from a storage cell: 1.
Page 86: Mounting And Dismounting Cartridges Manually
Mounting and Dismounting Cartridges Manually Mounting and Dismounting Cartridges Manually When the library is offline, you can mount a cartridge to a drive or dismount a cartridge from a drive. The following pages provide manual mount and dismount procedures for the tape drives. Note: If you manually mount any cartridges, you must manually dismount them and store them in the proper cell or remove them from the library.
Page 87: Mounting A Cartridge To A Dlt Drive
Mounting and Dismounting Cartridges Manually Mounting a Cartridge to a DLT Drive CAUTION: Potential equipment damage: Before you mount a cartridge into the drive, you must make sure power is on, and the Operate Handle indicator is steadily lit (not flashing). To mount a cartridge to a DLT drive: 1.
Page 88: Dismounting A Cartridge From A Dlt Drive
Mounting and Dismounting Cartridges Manually CAUTION: Potential equipment damage: You must insert the cartridge properly or you will damage the drive. Use only DLT cartridges for DLT drives. 6. Hold the cartridge so that the VOLSER label area is facing you and the write protect switch is on the right side of the cartridge, as shown in Figure 3-13.
Page 89: Mounting A Cartridge To A T9840 Drive
Mounting and Dismounting Cartridges Manually Mounting a Cartridge to a T9840 Drive CAUTION: Potential equipment damage: You must insert the cartridge properly or you will damage the drive. Use only T9840 cartridges for the T9840A and T9840B Tape Drives. To mount a cartridge to a T9840 drive: 1.
Page 90: Dismounting A Cartridge From A T9840 Tape Drive
Mounting and Dismounting Cartridges Manually 6. Wait for one of the following messages to display on the drive’s front panel: • The Ready F, a write-protected cartridge loads successfully. • The Ready U, a cartridge that is not write-protected loads successfully. •...
Page 91: Mounting A Cartridge To An Ultrium Drive
Mounting and Dismounting Cartridges Manually Mounting a Cartridge to an Ultrium Drive Figure 3-15. Mounting a Cartridge into an Ultrium Drive (C67293) C67293 C67293 1. Cartridge dismount button on the IBM Ultrium drive 2. Cartridge dismount button on the Seagate Ultrium drive 3.
Page 92: Dismounting A Cartridge From An Ultrium Drive
Mounting and Dismounting Cartridges Manually 4. Insert the cartridge into the Ultrium drive using the direction shown in Figure 3-15 on page 3-27. 5. Wait for the indicator on the front panel of the drive to stop blinking. 6. Place the drive back online Dismounting a Cartridge from an Ultrium Drive To dismount a cartridge from an Ultrium drive: 1.
Page 93: Placing The Library Online
Placing the Library Online Placing the Library Online To return or place the library online for automated operations: 1. Refer to your specific drive publications for instructions on making the drives ready. For a DLT drive, make sure the Operate Handle light is on and the handle is up.
Page 94: Adjusting The Display Screen
Adjusting the Display Screen Adjusting the Display Screen You also can change the operator panel’s screen characteristics from the main configuration menu. The screen characteristics are saved in non-volatile memory. To change the contrast and backlight (or brightness) of the operator panel screens: 1.
Page 95: Reviewing The Fsc Log
Reviewing the FSC Log Reviewing the FSC Log A StorageTek service representative or other service representative might ask you to review the library’s FSC log so that they can better analyze library-related problems. The FSC log records significant messages and errors that the library has generated during operation.
Page 96: Running Diagnostics
Running Diagnostics Running Diagnostics Diagnostic tests included in the library’s firmware let you test the functionality of important library components. You also may place the library in demonstration mode through the diagnostics menus. CAUTION: Diagnostic tests should be performed only by trained personnel. Before performing the diagnostic tests, ensure that the library and tape drives are offline.
Page 97: Running A Get-Put Loop
Running Diagnostics Table 3-1. L180 Library Drive Diagnostic Tests Test Description Clean Drive This function is not a test. It moves a specified cleaning cartridge from a reserved cell to a drive and initiates drive cleaning. When cleaning is complete, it returns the cleaning cartridge to a reserved cell.
Page 98: Operating In Demo Mode
100; the down arrow button decreases the value by 100. The maximum number of loops allowed is 2,000. Note: StorageTek recommends selecting only 100 loops to avoid premature wear on the hardware. 8. Press the button.
Page 99: 4: Storagetek Service
StorageTek Service This chapter describes what to do if problems occur with the L180 Tape Library. In some cases, you might be able to correct the problem. In other cases, you must contact your service provider to correct the problem.
Page 100: Customer Initiated Maintenance
To contact the CSS about a problem: 1. Use the telephone to call the StorageTek Customer Support Services at: 1-800-525-0369 (from within the United States) or 303-673-4056 (from outside the United States) or “StorageTek’s Worldwide Offices”...
Page 101: Storagetek's Worldwide Offices
Contact any of StorageTek’s worldwide offices to discuss complete storage, service, and support solutions for your organization. You can find address and telephone number information on StorageTek’s external web site at: http://www.storagetek.com/global...
Page 102 StorageTek’s Worldwide Offices This page intentionally left blank. Ninth Edition 95895...
Page 103: A: Cartridge Information
Contact your authorized Storagetek Selling Agent for labeled cartridges. For labels, contact EDP/Colorflex at 1-888-438-8362 or http://www.colorflex.com. For technical questions, contact the StorageTek Sales Support at 1-800-ask4stk or e-mail sales_support@storagetek.com. Handling a Cartridge Improper handling of cartridges can result in a loss of data or damage to a library component.
Page 104: Inspecting A Cartridge
Wipe all dust, dirt, and moisture from the cartridge with a lint-free cloth. Use StorageTek Tape Cleaner Wipes, PN 4046289-01, to clean the cartridges. These wipes are saturated with isopropyl alcohol. Do not let any solution touch the tape or get inside the cartridge.
Page 105: Repairing Leader Blocks
Accuracy ± 0.02 D Repeatability ± 0.01 D Aperture diameter 3.4 mm For more information about colored cartridges, contact your StorageTek marketing representative. Labels Besides the volume serial number, cartridges require a media identifier. Table A-1 Table A-2 show examples of cartridge labels.
Page 106: Table A-1. Data Cartridge Label Example
Labels Table A-1. Data Cartridge Label Example LTO Ultrium T9840 C67370 Media ID Labels The DLTtape Media ID The LTO Media ID label The Media ID label for label is incorporated is incorporated at the the T9840 is at the end into the tape label, and end of the tape label, of the tape label, and...
Page 107: Table A-2. Cleaning And Diagnostic Cartridge Label Examples
Labels Table A-2. Cleaning and Diagnostic Cartridge Label Examples DLT Diagnostic LTO Cleaning T9840 Diagnostic T9840 Cleaning C67369 Diagnostic and Cleaning Cartridge Label Identifiers DG = Diagnostic The cleaning Media DG = Diagnostic CLN = Cleaning plus Plus the Media ID ID labels include: Plus the Media ID U = Cleaning...
Page 108: Dlttape Cartridges
DLTtape Cartridges DLTtape Cartridges DLT cartridge tapes use a high-grade metal particle surface for the DLTtape cartridges and advanced metal powder formulation for the Super DLTtape I. These cartridges use a one-reel design with a simple tape path and stationary linear tape recording heads.
Page 109: Applying Labels
DLTtape Cartridges Applying Labels Cartridge labels reflect the cartridge media and usage. The letter located next to the last number in the VOLSER reflects the media-type and use: • Cleaning cartridges have CLN in the VOLSER • Diagnostic cartridges have DG in the VOLSER. Figure A-2 and perform these steps before inserting the label into the recessed area on the cartridge:...
Page 110: Setting The Write-Protect Switch
DLTtape Cartridges 5. See Figure A-2 on page A-7 and slide the label under the slots in the recessed area. If you prefer, peel the backing from the label and then slide it under the slots, pressing it into place. Setting the Write-protect Switch You can set the write-protect switch so the cartridge is write-enabled.
Page 111: Dlt Cartridge Environmental Specifications
DLTtape Cartridges DLT Cartridge Environmental Specifications The following specifications refer to the operating and storage environments for DLT cartridges. Table A-3. DLT Cartridge Environmental Specifications Operating environment Temperature 10º to 40ºC (50º to 104ºF) Relative humidity 20% to 80% noncondensing Wet-bulb temperature 25º...
Page 112: Lto Ultrium Cartridges
LTO Ultrium Cartridges LTO Ultrium Cartridges The Ultrium tape format is an implementation of the LTO (Linear Tape-Open) technology that is optimized for high capacity and performance. Ultrium tapes use a single reel cartridge to maximize capacity that makes them ideal for backup, restore, and archive applications.
Page 113: Applying Labels
LTO Ultrium Cartridges Applying Labels Figure A-4 on page A-10 shows the location of the VOLSER label. Refer to the specific tape drive manufacturer’s documentation for cartridge labeling instructions. Cartridge labels reflect the cartridge media and usage. The letter located next to the last number in the VOLSER reflects the media. Cleaning cartridges have CLN in the VOLSER;...
Page 114: Setting The Write-Protect Switch
LTO Ultrium Cartridges Setting the Write-protect Switch As shown in Figure A-5, you can set the write-protect switch so that the cartridge is write-enabled. • Slide the switch to reveal the “open lock” symbol to write-enable the tapes. In this position, the tape drive can write as well as read data. This setting is recommended when inserting cartridges into the tape library.
Page 115: Ultrium Cartridge Environmental Specifications
LTO Ultrium Cartridges Ultrium Cartridge Environmental Specifications The following specifications refer to the operating and storage environments for LTO Ultrium cartridges. Table A-4. LTO Ultrium Cartridge Environmental Specifications Operating environment 10º to 45ºC (50º to 113ºF) Temperature 20% to 80% Relative humidity 26ºC (79ºF) maximum Wet-bulb temperature...
Page 116: Storagetek T9840 Cartridges
StorageTek T9840 Cartridges StorageTek T9840 Cartridges The T9840 cartridge tape achieves fast access by having both the supply and take-up reels in the cartridge and by facilitating midpoint loading. The data cartridge tape has a capacity of 20 GB, uncompressed.
Page 117: Applying Labels
StorageTek T9840 Cartridges Applying Labels Figure A-6 on page A-14 shows the location of the VOLSER label. Refer to the T9840 Tape Drive documentation before applying labels to the cartridges. Setting the Write-protect Switch Refer to the T9840 Tape Drive documentation for instructions about how to set the cartridge’s write-protect switch.
Page 118: T9840 Cartridge Environmental Specifications
1. The conditioning time before use is 24 hours. 2. The shipping environment must not exceed the limit of the storage environment, archive or non-archive, for longer than 10 days. For more information about cartridges, visit StorageTek’s Web site at: http://www.storagetek.com/products/tape/services/ A-16...
Page 119: B: Library Statistics
Library Statistics Library statistics are divided into two major categories: counters and composite information. Both categories are explained in the following sections. Counters Counters are composed of 8-bit, 16-bit, and 32-bit elements. Each type is explained below. 8-bit Counters 8-bit counters have values from 0 to 2 minus 1 (or 255).
Page 120: 16-Bit Counters
Counters 16-Bit Counters 16-bit counters have values from 0 to 2 minus 1 (or 65,535). Table B-1. 16-Bit Counters Description Number of times the machine was booted. No distinction is made between powering-on or pressing the RESET button. Door Open Number of times the access door has been opened GET Retries Number of times a GET operation required a retry operation.
Page 121: 32-Bit Counters
Counters 32-Bit Counters 32-bit counters have values from 0 to 2 minus 1 (or 4,294,967,295). Table B-2. 32-Bit Counters Description Move Count Number of successful sets of GET/PUT operations (a single move consists of one GET and one PUT operation) Mount Count Same as move count, except that the move here involves mounting/dismounting a tape to/from a drive...
Page 122: Composite Information
Composite Information Composite Information Composite information contains statistics that keep track of groups of data, using units of time or some other discrete measurement. Composite information is supplied for cartridge access port (CAP) usage, library-wide drive performance, and individual drive performance. Cartridge Access Port (CAP) Usage CAP usage counters are 16-bit.
Page 123: Get Count
Composite Information GET Count The CAP GET count is the number of times a GET was executed from a CAP, with bins incrementing when a CAP is opened. This provides an indication of how a CAP is being used. For example, if 10 GETs were executed from a CAP, the “6–10”...
Page 124: Five Minute Job Rate
Composite Information Five Minute Job Rate This pool of statistics defines the hourly drive job rate the library was given during continuous five minute intervals. For example, if 13 mounts were executed during one five minute interval, the “151–175” usage bin (see below) would increment by one (13 mounts/5 minutes x 60 minutes/hour = 156 mounts per hour).
Page 125: Fifteen Minute Job Rate
Composite Information Fifteen Minute Job Rate This pool of statistics defines the hourly drive job rate the library was given during continuous fifteen minute intervals. For example, if 31 mounts were executed during one fifteen minute interval, the “101–125” usage bin (see below) would increment by one (31 mounts/15 minutes x 60 minutes/hour = 124 mounts per hour).
Page 126: Table B-7. Individual Drive Performance
Composite Information Table B-7. Individual Drive Performance General—No Data Transfer* Counter Explanation Serial Number Tracking is done by serial number rather than location. This allows for drive positional changes with no loss or inaccurate information. In addition, two extra information slots are allocated above the maximum drive count to allow for temporary swapping of drives.
Page 127: Glossary
Glossary This glossary defines abbreviations and new or special terms found in this or other L180 camera A system that reads VOLSER labels Tape Library manuals. on cartridges, instead of scanning the labels with a laser. A camera performs faster and more accurately than a laser scanner.
Page 128 Glossary diagnostic software that may directly or indirectly be used to indicate the field diagnostics Tests, accessible through the replaceable unit (FRU) that is probably library operator panel or the Horizon Library causing the error. Monitor, that allow a user to evaluate the Fibre Channel The National Committee for functionality of certain library components Information Technology Standards standard...
Page 129 The process by which opened and closed. In the L180 library, this the library robot retrieves a cartridge from a routine includes an audit of the cells.
Page 130 Remote Center The remote diagnostic and machine-readable. See also “volume center at StorageTek headquarters. serial (VOLSER) label.” RESET button This button will start a initial TTI Tape Transport Interface. A library program load to the library.
Page 131: Index
Index Numerics button, 2-2 contents screen, 2-6 9840 description, 1-8 cartridge environmental ejecting cartridges, 3-8 specifications, A-16 entering cartridges, 3-5 cartridge labels, A-15 magazine numbering, 2-17 cartridges, A-14 magazine retention cover, 3-7 loading a cartridge, 3-25 magazine status, 2-17 unloading a cartridge, 3-26 magazine status messages, 2-17 status messages, 2-17 capacity, tape library, 1-8...
Page 132 DNS entries, 2-13 DLT, 1-9 dWWN, 2-13 information on operator panel, 2-19 configuration main menu, 2-10 LTO, 1-9 contacting StorageTek, 4-2 status messages, 2-19 controlling software, 1-14 drop-off cell. See swap cell controls, 2-1 dWWN, described, 2-13 conventions in manual, xiv dynamic worldwide name, 2-13 CSC.
Page 133 3-10 Japanese compliance statement, xxiv FCC compliance statement, xxiii features 6U rack area, 1-11 L-Series Library Admin, 1-14 L180 Tape Library See library safety, 1-13 label, laser product, xviii fiber-optic cables labels connectors, xix cleaning and diagnostic, A-5...
Page 134 Index powering off, 3-2 procedures, 3-1 network reserved cells, 1-5 DNS configuration, 2-13 restarting, 3-4 dWWN, 2-13 safety, 1-13 network configuration screen, 2-13 Library Active indicator, location, 2-2 notes, description of, xiv library configuration screen, 2-10 library statistic screen, 2-5 library status screen, 2-3 license, internal code, xxv locating a cartridge manually, 3-21...
Page 135 1-13 remote users, 2-18 fiber optics, xviii status screen, 2-3 information, xvii storage capacity, tape library, 1-8 laser product label, xviii StorageTek rack-mounting, xx CSS telephone number, 4-2 screen Customer Resource Center (CRC), xvi CAP contents, 2-6 e-Partners site, xvi...
Page 136 A-3 description of, xiv ordering, A-1 Web sites targets, cell or arrays, 1-5 9840 cartridges, A-16 telephone number, StorageTek CSS, 4-2 Quantum, A-9 test screen See diagnostics write-protect switches 9840 cartridge tape, A-15 DLTtapes, A-8 LTO, A-12 Ultrium...
Page 137: Reader's Comment Form
Reader’s Comment Form Contact Us Submit your questions, comments, and suggestions to StorageTek’s Global Learning Solutions. We appreciate your correspondence and are committed to responding to you. Publication Information Publication Name: Publication Part Number: Questions and Comments: Note: Staples can cause problems with automated mail sorting equipment. Please use pressure sensitive or other gummed tape to seal this form.
Page 138 FIRST CLASS PERMIT NO. 2 LOUISVILLE, CO U.S.A. POSTAGE WILL BE PAID BY ADDRESSEE GLOBAL LEARNING SOLUTIONS MS 3256 STORAGE TECHNOLOGY CORPORATION ONE STORAGETEK DRIVE LOUISVILLE CO 80028-9989 FOLD HERE AND TAPE DO NOT STAPLE FOLD HERE AND TAPE If you would like a reply, please print:...
Page 140 World Headquarters Storage Technology Corporation One StorageTek Drive Louisville, Colorado 80028 USA Phone: 303.673.5151 Fax: 719.536.4053...

StorageTek L180 Operator's Manual

Summary of Changes

Contents

Figures

Tables

Preface

Safety

Notices

1: General Information

2: Controls and Indicators

Library Operation

4: Storagetek Service

A: Cartridge Information

B: Library Statistics

Glossary

Index

Reader's Comment Form

Quick Links

Need help?

Questions and answers

Related Manuals for StorageTek L180

Summary of Contents for StorageTek L180

Table of Contents
