Scanner Parts - Zebex Z-3191LE Service Manual

Scanner Parts

The scanner includes the following parts:
NO.
602-2SSHC0-681
1
863-319000-205
863-319000-206
540-D319X0-261
2
560-431901-505
560-431901-506
3 863-191LE0-500
4 613-191LE2-201
564-031900-383
5
564-031900-384
6 560-131901-523
514-831910-003
7
684-100000-541
8 564-031900-412
9 521-004000-8R0
10 521-614000-015
11 520-0140R5-6R0
12 521-003000-6R0
13 521-003000-8R0
14 603-031900-581
15 644-7319X0-000
16 031-005512-520
17 564-031900-362
Z-3191LE Service Guide
P/N
Protective rubber
Top cover assembly (gray)
Top cover assembly (black)
Waterproof net for speaker
Base cover (gray)
Base cover (black)
Laser engine
Decoder assembly
Cable base (gray)
Cable base (black)
Trigger button
Laser warning label
Dust cover
Buzzer sleeve
Self tapping screw,M3-8.0mm,round, Philip's head
Self tapping screw, M3-15.0mm,round, Trox head
Screw,M3*0.5-6.0mm, round, Philip's head (dyed black)
Self tapping screw,M2-6.0mm, round, Philip's head
Self tapping screw,M2-8.0mm, round, Philip's head
Rubber trigger button
Mylar Tape
FFC cable
Trigger button support
S
ERVICE
Name
G
UIDE
Quantity
4
1
1
1
1
1
1
1
1
1
1
2
2
1
2
2
1
2
1
1
5 / 9
