Summary of Contents for Zebex Z-3250
- Page 1 Z-3250 Handy Wireless Scanner Service Guide Revision History Changes to the original manual are listed below: Version Date Description of Version April. 29, 2014 Initial release July 17, 2015 New battery cover...
-
Page 2: Preface
This scanner is in conformity with CE standards. Please note that an approved, CE-marked power supply unit should be used in order to maintain CE conformance. This manual is in A4 format. Please check your printer setting before printing it out. Z-3250 Service Guide 2 / 8... -
Page 3: Table Of Contents
Table of Contents Preface..................................2 Important Notice ..................................2 Radio Notice...................................2 Radio and Television Interference............................2 For CE-Countries ...................................2 Table of Contents................................3 Scanner Parts ..................................4 Take Apart ..................................5 Before You Start ..............................5 Important Instructions ..............................5 Tools to Prepare ..................................5 Z-3250 Service Guide 3 / 8... -
Page 4: Scanner Parts
Bottom case assembly 571-170100-013 Sealing O-ring 520-512R35-5R0 Screw, M1.6-5.0mm 573-121800-012 Battery cover button 570-000000-001 Battery cover fixture 601-932500-003 Silicon button 521-073000-5R0 Self tapping screw, M2*5.0mm 521-002000-6R0 Self tapping screw,M1.6-6.0mm 542-090000-001 Dust cover protector 603-932500-001 Rubber ring Z-3250 Service Guide 4 / 8... -
Page 5: Take Apart
• Follow all instructions. • Heed all warnings. Tools to Prepare • Philips screwdriver. Please follow these steps to take apart the scanner. Remove the dust cover protector. Remove the battery from the scanner. Z-3250 Service Guide 5 / 8... - Page 6 ERVICE UIDE Unscrew the screw as marked. Remove the sealing O-ring, battery cover button, and battery cover fixture. Remove the screws as marked. Z-3250 Service Guide 6 / 8...
- Page 7 ERVICE UIDE Separate the top and bottom cover. Remove the silicon button. Remove the screws from the main board. Z-3250 Service Guide 7 / 8...
- Page 8 ERVICE UIDE Separate the main board from the bottom case. 10. Remove the rubber ring. Note: To assemble the device, please start from the last step and work your way backwards. Z-3250 Service Guide 8 / 8...
