USB 2.0+FireWire CardBus DV Kit

Quick Installation Guide

Introducing the USB 2.0+FireWire CardBus DV Kit
The USB 2.0+FireWire CardBus DV Kit is a complete DV editing kit
-- a combo design with USB 2.0 and FireWire (1394a) interfaces,
deluxe DV editing software (full DV, AVI, QuickTime, Windows
Media, RealNetworks, and MPEG2 support) and a 1394 6-pin/4-pin
DV cable.
Key Features and Benefits
• Combo design adds two USB 2.0 (480 Mbps) and two FireWire
(400 Mbps) ports into your system.
• Hot-swapping feature allows you to connect/disconnect
devices without first turning your system off
USB 2.0 interface:
• Compliant with USB specification rev. 2.0
• Supports high-speed (480 Mbps), full-speed (12 Mbps), and
low-speed (1.5 Mbps) data transfer modes for simultaneous
operation of multiple USB 2.0/1.1 devices
• Works with a various type of USB devices including hubs,
removable drives, digital cameras, scanners, CD-RWs, DVD-
ROMs, PC video cameras, printers, CF/SM/MMC/SD/
Memory Stick memory card readers, and more...
Note: USB 1.1 devices are limited to USB 1.1 speeds even
when they are connected to USB 2.0 host adapter or USB 2.0
hubs.
FireWire (1394a) interface:
• IEEE 1394-1995, P1394a-2000 and OHCI Interface Specification
1.1 compliant
• Supports serial bus data transfer rates of 100, 200 and 400
Mbps
• Works with various types of 1394 devices including DV
camcorders/cameras, hard disk drives, CD-RWs, DVD-ROMs,
removable drives, scanners, and other audio/video devices
04-0274A
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the US2273 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SIIG US2273

Summary of Contents for SIIG US2273

  • Page 1: Quick Installation Guide

    USB 2.0+FireWire CardBus DV Kit Quick Installation Guide Introducing the USB 2.0+FireWire CardBus DV Kit The USB 2.0+FireWire CardBus DV Kit is a complete DV editing kit -- a combo design with USB 2.0 and FireWire (1394a) interfaces, deluxe DV editing software (full DV, AVI, QuickTime, Windows Media, RealNetworks, and MPEG2 support) and a 1394 6-pin/4-pin DV cable.
  • Page 2 System Requirements • Pentium or equivalent notebook computer with an available CardBus Type II slot • Windows 98SE/ME/2000/XP Recommended system for Digital Video capturing/editing: • Pentium II or equivalent (400 MHz or above) notebook computer • 64 MB RAM and CD-ROM drive •...
  • Page 3 2. Click Next. At the Windows 98 Second edition Q242975 update window, click Yes to continue, then Yes again to accept the license agreement. 3. At Windows 98 Second edition Q242975 update window, click No not to restart Windows. 4. At the second Windows 98 Second edition Q242975 update window, click No.
  • Page 4 7. Click Finish to complete installation. Windows 2000 Installation 1. Insert the driver CD. Click Start, Run, type in D:\EHCI_ALi.exe, then click OK. (Replace D: with the drive letter of your CD-ROM) 2. Click Next, Finish, then restart Windows. 3. After Windows resumes, insert the CardBus. Note: Make sure the power supply is connected to the CardBus before installing into your notebook computer.
  • Page 5 To verify successful driver installation: 1. Check Device Manager to verify successful driver installation. Windows 98SE/ME: From the main desktop, right click My Computer, click Properties, then click Device Manager. Windows 2000/XP: Right click My Computer, click Manage, then click Device Manager. 2.
  • Page 6 Connecting DV Camcorder Before setting up the digital video camcorder, make sure to verify the driver for the adapter has been successfully installed in your system and follow the setup procedures listed below. 1. Boot up your system. 2. Connect the 4-pin connector of the provided FireWire (1394) 6-pin/4-pin DV cable into your digital camcorder, and connect the 6-pin connector into an available port on the 1394 adapter.

  • Page 7: Technical Support

    RMA number posted on the outside of the shipping carton. Step 3: Ship the Product You are responsible for the cost of shipping back to SIIG at the following address: SIIG, Inc.
  • Page 8 Fremont, CA 94538-3152 USB 2.0+FireWire CardBus DV Kit is a trademark of SIIG, Inc. SIIG and SIIG logo are registered trademarks of SIIG, Inc. Microsoft and Windows are registered trademarks of Microsoft Corporation. Pentium is a registered trademark of Intel Corporation.
