SIIG US2273 Quick Installation Manual

Usb 2.0+firewire cardbus dv kit
Hide thumbs Also See for US2273:

Advertisement

Quick Links

Download this manual
USB 2.0+FireWire CardBus DV Kit
Quick Installation Guide
Features and Benefits
•
Fully compliant with USB specifications revision 2.0
and IEEE 1394-1995, P1394a-2000 and OHCI 1.1
Standards
•
Combo CardBus PC Card design allows you to add
the USB 2.0 and FireWire (1394a) interface into your
notebook or Tablet PC at once
•
Two USB 2.0 ports support 480Mbps, 12Mbps,
1.5Mbps data transfer modes
•
Two FireWire ports support serial bus data transfer
rates of 400 Mbps, 200 Mbps, and 100 Mbps
•
Includes Ulead VideoStudio editing software
•
Includes a high quality switching power adapter to
provide standard power output for the USB ports
NOTE: USB 1.1 devices are limited to USB 1.1
speeds even when they are connected to USB 2.0
host adapter or USB 2.0 hubs.
System Requirements
•
Pentium or equivalent notebook PC with an available
CardBus Type II slot
•
Windows 98SE/ME/2000/XP
Recommended system for Video capturing/editing:
•
Pentium III or above notebook PC
•
128MB of RAM and CD-ROM drive
•
4GB of available hard disk space
•
Windows 98SE or later
04-0274B
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the US2273 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SIIG US2273

Summary of Contents for SIIG US2273

  • Page 1 USB 2.0+FireWire CardBus DV Kit Quick Installation Guide Features and Benefits • Fully compliant with USB specifications revision 2.0 and IEEE 1394-1995, P1394a-2000 and OHCI 1.1 Standards • Combo CardBus PC Card design allows you to add the USB 2.0 and FireWire (1394a) interface into your notebook or Tablet PC at once •...
  • Page 2 Package Contents • (1) USB 2.0+FireWire CardBus • (1) Switching power adapter • (1) Driver CD • (1) Ulead VideoStudio DV editing software CD • (1) 1394 6-pin/4-pin DV cable • This quick installation guide Layout Power Adapter Jack* FireWire** 4-pin FireWire** 6-pin USB 2.0 Figure 1.

  • Page 3: Hardware Installation

    Hardware Installation General instructions for installing the card are provided below, since the design of notebook computers may vary. Refer to your system’s reference manual for further information, if needed. Insert the PC Card into the CardBus Type II slot of your notebook computer with its 68-pin connector facing the slot.

  • Page 4: Software Installation

    Software Installation Important: Make sure the driver is installed prior to inserting the USB 2.0+FireWire CardBus. 2-1) Windows 98SE Driver Installation Insert the driver CD. Click Start, Run, type in X:\Setup.exe, then click OK. (Replace X: with the drive letter of your CD-ROM) Click Next, then Finish to restart Windows.
  • Page 5 2-2) Windows ME Driver Installation Insert the driver CD. Click Start, Run, type in X:\Setup.exe, then click OK. (Replace X: with the drive letter of your CD-ROM) Click Next, then Finish to restart Windows. After Windows resumes, insert the CardBus. At the Add New Hardware Wizard, choose Automatic search...
  • Page 6 2-4) Windows XP Driver Installation NOTE: If you have Windows XP with Service Pack 1 (SP1) or later, the drivers will be installed automatically by the operating system. Otherwise, follow the instructions below. Insert the driver CD. Click Start, Run, type in X:\Setup.exe, then click OK.
  • Page 7 2-5.1) Windows 98SE/ME a) Under the 1394 Bus Controller: - OHCI Compliant IEEE 1394 Host Controller b) Under the Network Adapters: (WinME only) - NDIS 1394 Net Adapter c) Under the Universal Serial Bus controllers: - ALi PCI to USB Enhanced Host Controller - ALi PCI to USB Open Host Controller - ALi PCI to USB Open Host Controller - ALi PCI to USB Open Host Controller...
  • Page 8 - USB Root Hub - USB Root Hub - USB Root Hub 2-5.3) Windows 2000 (with sp4 or later)/XP (with sp1 or later): a) Under the IEEE 1394 Bus host controllers: - OHCI Compliant IEEE 1394 Host Controller b) Under the Network Adapters: (WinXP only) - 1394 Net Adapter c) Under the Universal Serial Bus controllers: - ALi PCI to USB Enhanced Host Controller...

  • Page 9: Connecting A Dv Camcorder

    2-6) Ulead VideoStudio software installation: The USB 2.0+FireWire CardBus DV Kit includes Ulead VideoStudio digital video editing software for producing home videos complete with attractive titles, transitions and sounds. Insert the Ulead VideoStudio DV software CD. Auto- run should start automatically. If not, click Start, Run, type in X:\Autorun.exe, then click OK.
  • Page 10 To verify successful DV camcorder setup: Check Device Manager to verify successful driver installation. Windows 98SE/ME: From the main desktop, right click My Computer, then click Properties. Click Device Manager tab. Windows 2000/XP: Right click My Computer, then click Manage. Click Device Manager. Under Imaging Device(s), a Microsoft DV Camera and VCR or DV Camcorder should be displayed.

  • Page 11: Technical Support

    The 5-year manufacturer warranty supplied with this product is offered by SIIG, Inc. If you should happen to encounter any problems with this product, please follow the procedures below.
  • Page 12 Fremont, CA 94538-3152 USB 2.0+FireWire CardBus DV Kit is a trademark of SIIG, Inc. SIIG and SIIG logo are registered trademarks of SIIG, Inc. Microsoft and Windows are registered trademarks of Microsoft Corporation. Pentium is a registered trademark of Intel Corporation.
