- Page 1 UltraATA 133/100 Pro User’s Manual SIIG’s ONLINE SUPPORT and Product Registration Visit SIIG’s web site at www.siig.com and click SUPPORT/DRIVERS for instant technical support. Also, click REGISTRATION FORM to register your product...
- Page 2 1. What features encouraged you to purchase this product? (check all that apply) Good price Good value 2. Is this the first SIIG product you have ever purchased? If not, what other SIIG products do you own? ___________________________________________ 3. System Configuration:...
- Page 3 Comments: ___________________________________________ ___________________________________________ ___________________________________________ ___________________________________________ ___________________________________________ ___________________________________________ ___________________________________________ ___________________________________________ ___________________________________________ ___________________________________________ ___________________________________________ ___________________________________________ ___________________________________________ ___________________________________________ ___________________________________________ ___________________________________________ ___________________________________________ ___________________________________________ ___________________________________________ ___________________________________________ ___________________________________________ ___________________________________________ ___________________________________________...
- Page 4 UltraATA 133/100 Pro is a trademark of SIIG, Inc. SIIG and SIIG logo are registered trademarks of SIIG, Inc. Power Mac is a trademark and Mac is a registered trademark of Apple Computer, Inc. All other names used in this publication are for identification only and may be trademarks of their respective companies.
-
Page 5: Table Of Contents
User's Manual Chapter 1: Introduction 1-1 Unpacking the UltraATA 133/100 Pro ... 1-1 1-1.1 Static Electricity Precaution ... 1-2 1-1.2 Record the Serial Number ... 1-2 1-2 Introducing the UltraATA 133/100 Pro ... 1-3 1-2.1 Key Features and Benefits ... 1-3 1-2.2 System Requirements ... -
Page 6: About This Manual
About This Manual The purpose of this manual is to introduce you to your UltraATA 133/100 Pro. It will guide you on how to install the card and software for proper operation in your computer. Please save this manual for future reference in the event you wish to connect other devices to your system. - Page 7 User's Manual...
-
Page 8: Chapter 1 Introduction
Chapter 1 Introduction Thank you for your purchase of the UltraATA 133/100 Pro. SIIG’s goal is to provide its customers with reliable, high quality products and customer support. The purpose of this comprehensive user’s manual is to: • introduce you to your UltraATA 133/100 Pro features and benefits •... -
Page 9: 1-1.1 Static Electricity Precaution
Handle cards only by their edges. 1-1.2 Record the Serial Number In order for SIIG's Technical Support or Customer Service Department to give you prompt service, you will need the following product information. The serial number label is located on the side of the box and on the back of the board. -
Page 10: Introducing The Ultraata 133/100 Pro
• Two independent IDE channels, supports up to four Ultra ATA hard drives and CD-R/RWs that support Adaptec Toast burning software (see drive compatibility list on www.siig.com) • Breaks the 137GB barrier! Supports various types of large capacity hard disk drives •... -
Page 11: 1-2.3 Board Layout
User's Manual 1-2.3 Board Layout Ultra ATA 133/100 Connectors IDE2 IDE1 Ultra ATA/133/100 Chipset Figure 1-1. UltraATA 133/100 Pro Board Layout... -
Page 12: Chapter 2 Installation
This chapter will guide you through the installation of the UltraATA 133/100 Pro into your computer. Hardware Installation General instructions for installing the card are provided below. If needed, please refer to your computer’s reference manual for more information. Caution: Static Electricity Discharge may permanently damage your system. -
Page 13: Device Connection
User's Manual Note: Hold the board by its external edges only. Try to avoid touching the components, connectors or pins. Figure 2-1: Installing the board Device Connection The UltraATA 133/100 Pro is a dual channel Ultra ATA/133 controller that supports up to four IDE hard disk drives or CD-R/ RW drive. - Page 14 2. Attach one connector on the long end of the Ultra ATA ribbon cable to the board's IDE connector and the other connector(s) to your hard disk drive(s). Make sure pin 1 on the cable (indicated by the colored stripe) matches pin 1 on the board's IDE connector and your hard disk drive(s).
-
Page 15: Software Installation
User's Manual Software Installation This section provides information on how to install the UltraATA 133/100 Pro driver in your Power Mac. Please refer to the Mac OS manual to familiarize yourself with Drive Setup and OS Installation routines. 2-3.1 Driver Installation for Mac OS 8.6 For a fresh OS 8.6 installation: 1. -
Page 16: 2-3.2 Driver Installation For Mac Os 9.X
2-3.2 Driver Installation for Mac OS 9.x For a fresh OS 9.x installation: 1. Install the UltraATA 133/100 Pro and attached drives. 2. Boot up your computer with the Mac OS 9.x CD-ROM. Press and hold letter C on the keyboard while your system is booting to boot from CD-ROM. -
Page 17: 2-3.3 Driver Installation For Mac Os X
User's Manual 2-3.3 Driver Installation for Mac OS X For a fresh OS X installation: 1. Install the UltraATA 133/100 Pro and attached drives. 2. Boot up your computer with the Mac OS X CD-ROM. Press and hold letter C on the keyboard while your system is booting to boot from CD-ROM. -
Page 18: Verifying Installation
Verifying Installation After you succesfully initialize the hard drive, new Untitled drive(s) icon will appear on the desktop. Please check Apple System Profiler for successful installation. 2-4.1 Verify Mac OS 8.6/9.x Installation 1. Click Apple logo located on the upper left corner of the desktop. - Page 19 User's Manual...
-
Page 20: Overview
3. Technical Support 4. Return Merchandise Authorization (RMA) 3-2 Web Site Visit SIIG’s Web site at www.siig.com for on-line technical support, product features, drivers updates, upgrade solutions and where-to-buy information. Your opinions of SIIG products are very important to us. Through your feedback, SIIG can continue to deliver quality, innovative products to you. -
Page 21: Technical Support
If your product fails to be in good working order during the warranty period, you may return it to SIIG for repair or replacement at SIIG's option. To return the product, you need to follow these steps. - Page 22 RMA number posted on the outside of the shipping carton. Step 3: Ship the Product You are responsible for the cost of shipping back to SIIG at the following address: SIIG, Inc. 6078 Stewart Ave.
- Page 23 User's Manual...
- Page 24 1. calling (510) 413-5333 or 2. faxing (510)657-5962 or 3. emailing service@siig.com. The RMA number should be clearly displayed on the outside of the returned package and on the accompanying RMA form. The Company will refuse any package without a RMA number.
- Page 25 02-0250E...
- Page 26 03-0311A...
