FASTRON. VISION Series Programming Manual page 4

Programming the Controller
Alarm X Done will be displayed along with either
AUTOMATIC or MANUAL. Use the left or right arrow
keys to change between the 2 settings. Then
press the "P" key.
Alarm X Tone will be displayed with either SHORT,
MEDIUM, LONG, DOUBLE, LONG/SHORT, or NONE. Use the
left or right arrow keys to change between the 6
settings. Then press the "P" key.
NOTE: You can set up to 3 alarms per key.
Follow the above directions if 3 are needed.
Hold Time will be displayed with the current time
XX:XX. To change, type in a new hold time. Then
press the "P" key.
Hold Temp will be displayed with the current hold
temperature XXXF. To change, type in a new hold
temperature. Then press the "P" key.
Hold Done will be displayed along with either
AUTOMATIC or MANUAL. Use the left or right arrow
keys to change between the 2 settings. Then
press the "P" key.
Hold Fan Speed will be displayed then either HIGH or
LOW. Use the left or right arrow keys to change
between the 2 settings. Then press the "P" key.
Exit Programming
From All being displayed Scroll up to Exit and
press the "P" key. Recipe will be displayed. Scroll
down to Exit and press the "P" key.
This document contains confidential information. The dissemination, publication, copying, or duplication of this document or the software described herein without prior written authorization is strictly prohibited.
4
Vision Vertical Oven Controller
System Programming—3228
Entering System Programming and
Changing System Settings
Press and hold the "P" for 3 seconds.
Product Cnt will be displayed. Press the down
arrow key.
Programming will be displayed. Press the "P" key.
ENTER CODE will be displayed.
From ENTER CODE, type in 3228, then press the "P"
key.
Display will show System. Press the "P" key.
Appliance Type will be displayed then either ELECTRIC
FULL, ELECTRIC HALF, GAS HALF, GAS FULL. To change be-
tween the 4 settings, use the left and right arrow
keys. Then press the "P" key.
Language will be displayed, then either ENGLISH or
OTHER. Use the left or right arrow keys to change
between the 2 settings. Then press the "P" key.
Tone Volume will be displayed, then either 1-4 or
NONE. Use the left or right arrow keys to change
between the 5 settings. Then press the "P" key.
Temperature will be displayed, then either F or C.
Use the left or right arrow keys to change be-
tween the 2 settings. Then press the "P" key.
Hold Time will be displayed with the current time
XX:XX. To change the hold time, type in your new
time. Then press the "P" key.
Hold Temp will be displayed with the current hold
temp XXXF. To change the hold temp, type in your
new temperature. Then press the "P" key.
Hold Done will be displayed along with either AUTO-
MATIC or MANUAL. Use the left or right arrow keys to
change between the 2 settings. Then press the "P"
key.
www.fastinc.com 1-800-243-9271
229-51414C © 2008-2010 FAST
