Mocka Nixon Three Drawer Assembly Instructions Manual page 6

Nixon Three Drawer
ASSEMBLY INSTRUCTIONS
9
Drawers x3
16
B
17
14
Insert 5x bolts (A) into panel [14]. Secure side panels [16] and [17] with
4x locking nuts (B). Tighten with a screwdriver. Slide panel [18] down
between the grooves of side panels [16] and [17].
mocka.co.nz | mocka.com.au
A
A
A
A
A
14
18
16
17
14
10
19
B
16
18
D
15
D
16
Attach panel [19] behind panel [18] using 1x locking nut (B). Attach panel
[15] to panels [16], [17] and [19] using 5x screws (D) as shown. Attach
1x slide rail (F) onto each panel [16] and [17] and secure with 2x screws
(G) for each. Tighten all with a screwdriver.
17
G
F
D
14
F
19
G
17
15
16
6
