Mocka Nixon Three Drawer Assembly Instructions Manual page 5

Nixon Three Drawer Jolt Wardrobe
ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS
7
K
K
4
C
C
3
Attach panel [4] to the main unit using 4x dowels (C) and secure with
4x screws (K). Tighten with the allen key (N).
mocka.co.nz | mocka.com.au
mocka.co.nz | mocka.com.au
K
N
K
C
C
2
1
8
E
E
E
E
E
3
Attach the leg panels to panel [4] and secure with 10x screws (E).
Tighten with a screwdriver.
E
E
E
4
E
2
5 5
