TimeWizard
Procedure G. TimeWizard Installation and Operation
Step
Use this procedure to install the firmware in the TimeSource 3000 to configure the GPS and
Holdover alarms, using the TimeWizard application.
Requirements:
1. A PC running Windows 95/98/NT 4.0/2000/XP.
2. The TimeSource 3000 CD labeled 992-72010-06 Rev. B, Version 1.06.04.
3
1 Connect the TimeSource 3000 to the PC with a serial cable.
2 Insert the TimeSource 3000 CD labeled 992-72010-06 Rev. B Version 1.06.04 into
the PC's CD-ROM drive.
If AutoRun is enabled on the PC, the CD should automatically launch the Install
Shield wizard for installation of the TimeWizard application. If Install Shield
launches, continue with Step 5. If Install Shield does not automatically launch,
continue with the next step.
3 The Windows Explorer, double-click "setup.exe" in the root directory of the CD to
start the Install Shield wizard.
4 Follow the prompts in the Install Shield wizard to install TimeWizard in the
preferred directory.
Continue with the next step after the TimeWizard installation is complete.
90
S S S S S S S S S
The TimeWizard Software Installation application was created to facilitate installing
software upgrades for the TimeSource 3000. Procedure G shows how to install the
TimeWizard application and how to use TimeWizard to download software
upgrades.
Hardware Installation
Install the TimeWizard Software
S S S S S S S S S
Procedure
S S S S S S S S S
TimeSource 3000
097-72000-02 Issue 6: October 2003
S S S S S
Installation
