Retrieve Performance Monitoring (cont'd)
Note:
•
•
•
•
TimeSource 3000
TL1 Reference
097-72000-02 Issue 6: October 2003
S S S S S S S S S
PHASE1S Data types:
One 15 minute bin from the last 24 hours of data is displayed as 900 seconds of data.
To select a 15 minute bin, enter mondat and montm. Any mondat/montm
combination outside of the past 24 hour window is denied. Any time increment may
be entered. The system rounds the value to the nearest bin.
Entered minutes of 1 to 15 correspond to the first 15 minute bin, 16 to 30 correspond
to the second 15 minute bin, etc.
The first monitor value is the first second of the 900 second window.
The 900 seconds of data is broken into 9 groups of 100 seconds. For each group of
100 seconds, the first value is the absolute 1 second phase for that group. The
absolute 1 second phase value is followed by 99 seconds of delta phase values.
