When the Board is connected to the USB port of the host PC, the green D4 LED will illu-
minate (turn ON).
Schematic diagrams of the Z51F0811 Evaluation Board are presented
21
The physical dimensions of the Board are: 1.61" x 0.76" (40.9 mm x 19.3 mm).
Introduction
of this document.
on pages 20 through
