- Page 1 ™ Z8051 Family of 8-Bit Microcontrollers Z51F0811 MCU Evaluation Kit User Manual UM024201-0212 Copyright ©2012 Zilog ® , Inc. All rights reserved. www.zilog.com...
- Page 2 Z8, Z8 Encore!, Z8 Encore! XP and Z8 Encore! MC are trademarks or registered trademarks of Zilog, Inc. All other product or service names are the property of their respective owners.
-
Page 3: Revision History
Z51F0811 MCU Evaluation Kit User Manual Revision History Each instance in the Revision History table below reflects a change to this document from its previous version. Revision Date Level Description Page Original issue. 2012 UM024201-0212 Revision History... - Page 4 Z51F0811 MCU Evaluation Kit User Manual Revision History UM024201-0212...
- Page 5 Z51F0811 MCU Evaluation Kit User Manual Table of Contents Revision History ............iii Table of Contents .
- Page 6 Z51F0811 MCU Evaluation Kit User Manual Table of Contents UM024201-0212...
- Page 7 Z51F0811 MCU Evaluation Kit User Manual List of Figures Figure 1. Z51F0811 Evaluation Board ........2 Figure 2.
- Page 8 Z51F0811 MCU Evaluation Kit User Manual viii List of Figures UM024201-0212...
- Page 9 Z51F0811 MCU Evaluation Kit User Manual List of Tables Table 1. Z51F0811000KIT Contents ........1 Table 2.
- Page 10 Z51F0811 MCU Evaluation Kit User Manual List of Tables UM024201-0212...
-
Page 11: Introduction
The Kit features a small Evaluation Board consisting of four LEDs, three pushbuttons, port pin headers and a UART-to-USB port. The Board features the Z51F0811 MCU in a 32-pin QFN package, plus a DBG connector to connect the board to a host development PC using the Z8051 USB On-Chip Debugger (OCD) cable. -
Page 12: Supported Operating Systems
Z51F0811 MCU Evaluation Kit User Manual Figure 1 displays an image of the Z51F0811 Evaluation Board. F.P.O. Figure 1. Z51F0811 Evaluation Board Supported Operating Systems The Z51F0811 Evaluation Board and the Z8051 On-Chip Debugger support the following operating systems: •... -
Page 13: Z51F0811 Evaluation Board Description
1 green LED indicating USB power: D4 • 3 pushbuttons: – SW1: RESET – SW2 and SW3 are connected to the GPIO pins on the Z51F0811 MCU • USB connector: P1 • OCD connector: J1, J2 • USB to UART interface: U2 •... - Page 14 Z51F0811 MCU Evaluation Kit User Manual When the Board is connected to the USB port of the host PC, the green D4 LED will illu- minate (turn ON). Schematic diagrams of the Z51F0811 Evaluation Board are presented on pages 20 through of this document.
-
Page 15: Install The Z8051 Ocd Software And Documentation
The Z8051 On-Chip Debugger (OCD) interface is the interface by which your PC will communicate with the Z51F0811 MCU to download and execute code. In addition to the OCD, software such as development tools and sample applications will be installed. -
Page 16: Figure 4. The Found New Hardware Wizard Welcome Screen
Z51F0811 MCU Evaluation Kit User Manual 1. Connect the OCD hardware to the USB port of your PC by connecting the A-Male end of one of the two USB A (male)-to-Mini-B cables with the host PC’s USB port, and connect the Mini-B end to the OCD device. -
Page 17: Ftdi Usb-To-Uart Driver Installation
FTDI USB-to-UART Driver Installation An FTDI USB-to-UART driver is required to allow your PC to communicate through its USB port to the on-chip UART of the Z51F0811 MCU. Observe the following procedure to perform these connections. 1. Ensure that the USB cable is not plugged in to the Z51F0811 Evaluation Board’s P1 connector. -
Page 18: Figure 6. A Successful Usb-To-Uart Driver Installation
Z51F0811 MCU Evaluation Kit User Manual 3. The installation process will begin and you should observe output similar to the fol- lowing messages on the screen of your PC: 32-bit OS detected <installation path>\dpinstx86.exe Installation driver FTDI CDM driver installation process completed.... - Page 19 Z51F0811 MCU Evaluation Kit User Manual Note: To launch the Device Manager on Windows 7 systems, launch the Start menu, enter device manager in the Search programs and files field, and press the Enter key. To open the Device manager on earlier Windows systems, navigate via the following path:...
-
Page 20: Configure The Z8051 Ocd And Z51F0811 Evaluation Board
Z51F0811 MCU Evaluation Kit User Manual Configure the Z8051 OCD and Z51F0811 Evaluation Board Observe the following procedure to set up and configure the Z8051 On-Chip Debugger and the Z51F0811 Board. 1. Connect the Z8051 On-Chip Debugger (OCD) to the host PC’s USB port. If you haven’t already performed your hardware connections, see the... -
Page 21: Figure 8. Connecting The Usb Mini-B Cable To The Board
Z51F0811 MCU Evaluation Kit User Manual F.P.O. Figure 8. Connecting the USB Mini-B Cable to the Board UM024201-0212 Configure the Z8051 OCD and Z51F0811 Evaluation... -
Page 22: Build And Run The Z51F0811 Demo Project
4. Run the Z8051 OCD software. From the Start menu, navigate to All Programs → Zilog Z8051 Software and Documentation <version_number> Zilog Z8051 OCD <version_number> . Once launched, the program will display Connected, as shown in Figure 9. Build and Run the Z51F0811 Demo Project... -
Page 23: Figure 9. Initial Ocd Screen
Z51F0811 MCU Evaluation Kit User Manual F.P.O. Figure 9. Initial OCD Screen Note: For a free download of the latest version of the OCD software, visit the Zilog website navigate via the menu to Tools and Software Software Downloads 5. In the Debugger window, select... -
Page 24: Figure 10. Configuration Dialog
Z51F0811 MCU Evaluation Kit User Manual Figure 10. Configuration Dialog 8. Click the button to open the On-Chip Debugger’s main window. A typical OCD Write window is shown in Figure 11. Build and Run the Z51F0811 Demo Project UM024201-0212... -
Page 25: Figure 11. A Typical On-Chip Debugger Window
Z51F0811 MCU Evaluation Kit User Manual F.P.O. Figure 11. A Typical On-Chip Debugger Window Note: If the dialog does not appear in the Z8051 OCD Debugger, navigate Code Disassemble via the View menu to select Code Disassemble 9. Click the toolbar icon, shown in Figure 12. -
Page 26: Hyperterminal Configuration
Z51F0811 MCU Evaluation Kit User Manual Figure 12. Reset & Go Toolbar Icon 10. Similar projects that you can use as references are listed in Table 5 on page 18. HyperTerminal Configuration A communications program such as HyperTerminal can be used on Windows XP systems to view the messages from the Z51F0811 Evaluation Board. -
Page 27: Figure 13. Demo Program Menu In Hyperterminal
Z51F0811 MCU Evaluation Kit User Manual Figure 13. Demo Program Menu in HyperTerminal UM024201-0212 Build and Run the Z51F0811 Demo Project... -
Page 28: Sample Projects And Documentation
Z51F0811 MCU Evaluation Kit User Manual Sample Projects and Documentation A number of sample projects are included on the CD that ships with the Z51F0811 Evalu- ation Kit, and their locations, listed in Table 5, will be accessible upon installation. - Page 29 Table 6. Z51F0811 Evaluation Kit Documentation (Continued) Description Document Location Z8051 OCD and ISP User Manual UM0240 Documentation\Tools_Documentation Z51F0811 MCU Evaluation Kit User Manual UM0242 Documentation\Tools_Documentation Z51F3220 MCU Development Kit User Manual UM0243 Documentation\Tools_Documentation Z8051 Tools Product User Guide PUG0033...
-
Page 30: Schematic Diagrams
Z51F0811 MCU Evaluation Kit User Manual Schematic Diagrams Figures 14 and 15 display schematic diagrams of the Z51F0811 Evaluation Board. Figure 14. Z51F0811 Evaluation Board, #1 of 2 Schematic Diagrams UM024201-0212... -
Page 31: Figure 15. Z51F0811 Evaluation Board, #2 Of 2
Z51F0811 MCU Evaluation Kit User Manual Figure 15. Z51F0811 Evaluation Board, #2 of 2 UM024201-0212 Schematic Diagrams... -
Page 32: Appendix A. Ocd Driver Installation On Windows Vista Systems
Z51F0811 MCU Evaluation Kit User Manual Appendix A. OCD Driver Installation on Windows Vista Systems The driver programs for the Z8051 On-Chip Debugger are copied to the development PC during the software and documentation installation. In the following procedure for PCs running Windows Vista 32- and 64-bit operating systems, ensure that the target side of the OCD will remain unconnected while you install these drivers. -
Page 33: Figure 17. Install Device Driver Dialog, Windows Vista
Z51F0811 MCU Evaluation Kit User Manual 3. Depending on your development PC’s User Account Control settings, Windows may ask for permission to continue the installation. Click Continue 4. When you see the Installing Device Driver dialog shown in Figure 17, do not click . -
Page 34: Figure 18. Couldn't Find Driver Dialog, Windows Vista
Z51F0811 MCU Evaluation Kit User Manual Figure 18. Couldn’t Find Driver Dialog, Windows Vista 5. Select Browse my computer for driver software (advanced) to display the dialog shown in Figure 19, which prompts you to key in or browse for the location of the file. -
Page 35: Figure 19. Browse For Driver Dialog, Windows Vista
Z51F0811 MCU Evaluation Kit User Manual Figure 19. Browse For Driver Dialog, Windows Vista UM024201-0212 Schematic Diagrams... -
Page 36: Figure 20. Can't Verify Publisher Dialog, Windows Vista
Z51F0811 MCU Evaluation Kit User Manual 6. When Windows prompts you whether to install or not install, click Install this driver and wait until the installation is completed (Windows may prompt software anyway you more than once). Figure 20. Can’t Verify Publisher Dialog, Windows Vista... -
Page 37: Figure 21. Successfully Installed Dialog, Windows Vista
Z51F0811 MCU Evaluation Kit User Manual 7. When the installation is complete, the screen shown in Figure 21 will appear. Click to exit the OCD driver installation. Close Figure 21. Successfully Installed Dialog, Windows Vista UM024201-0212 Schematic Diagrams... -
Page 38: Appendix B. Ocd Driver Installation On Windows 7 Systems
Z51F0811 MCU Evaluation Kit User Manual Appendix B. OCD Driver Installation on Windows 7 Systems The driver programs for the Z8051 On-Chip Debugger are copied during the software and documentation installation. In the following procedure for PCs running Windows 7 32- and 64-bit operating systems, ensure that the target side of the OCD will remain uncon- nected while you install these drivers. -
Page 39: Figure 23. Driver Software Installation Dialog, Windows 7
Z51F0811 MCU Evaluation Kit User Manual Figure 23. Driver Software Installation Dialog, Windows 7 UM024201-0212 Schematic Diagrams... -
Page 40: Figure 24. Device Manager Dialog, Windows 7
Z51F0811 MCU Evaluation Kit User Manual 3. If Zilog Z8051 USB OCD appears in the Device Manager (as highlighted in Figure 24), the OCD driver software has been successfully installed. Figure 24. Device Manager Dialog, Windows 7 Schematic Diagrams UM024201-0212... -
Page 41: Customer Support
User Manual Customer Support To share comments, get your technical questions answered, or report issues you may be experiencing with our products, please visit Zilog’s Technical Support page at http://sup- port.zilog.com. To learn more about this product, find additional documentation, or to discover other fac-... - Page 42 Z51F0811 MCU Evaluation Kit User Manual Customer Support UM024201-0212...
