Page 1: Evaluation Kit
Z8F08200100KIT Z8 Encore! 8K/4K MCU Evaluation Kit User Manual Preliminary UM015003-0603 ZiLOG Worldwide Headquarters • 532 Race Street • San Jose, CA 95126-3432 Telephone: 408.558.8500 • Fax: 408.558.8300 • www.ZiLOG.com... - Page 2 Document Disclaimer ZiLOG is a registered trademark of ZiLOG Inc. in the United States and in other countries. All other products and/or service names mentioned herein may be trademarks of the companies with which they are associated. ©2003 by ZiLOG, Inc. All rights reserved. Information in this publication concerning the devices, applications, or technology described is intended to suggest possible uses and may be superseded.
- Page 3 Z8 Encore! 8K/4K MCU Evaluation Kit User Manual Safeguards The following precautions must be observed when working with the devices described in this document. Always use a grounding strap to prevent damage resulting from electro- Caution: static discharge (ESD). Disclaimer Preliminary UM015003-0603...
-
Page 4: Table Of Contents
Z8 Encore! 8K/4K MCU Evaluation Kit User Manual Table of Contents Introduction ..........1 Kit Contents . -
Page 5: List Of Figures
Z8 Encore! 8K/4K MCU Evaluation Kit User Manual List of Figures Figure 1. Z8 Encore! MCU Evaluation Kit Contents ....2 Figure 2. Z8 Encore!™ 8K/4K Evaluation Board ....6 List of Tables Table 1. -
Page 6: Introduction
8K/4K MCU Evaluation Kit User Manual Introduction The Z8 Encore!™ 8K/4K MCU is the part of the line of ZiLOG micro- controller products. The Z8 Encore! MCU Evaluation Kit (Z8F08200100KIT) enables users to become familiar with the hardware and software tools available with this product. -
Page 7: Software (On Cd-Rom)
Z8 Encore! 8K/4K MCU Evaluation Kit User Manual Packaging CD-ROM Containing Documentation Power Supply Smart Cable Evaluation Board Figure 1. Z8 Encore! MCU Evaluation Kit Contents Software (on CD-ROM) • ZDS II- Z8 Encore! IDE with ANSI C-Compiler • Sample code •... -
Page 8: System/Software Requirements
Z8 Encore! 8K/4K MCU Evaluation Kit User Manual • Z8 Encore! 8K/4K technical documentation (on CD-ROM) – Evaluation Kit User Manual – ZDS II - IDE User Manual – eZ8 CPU User Manual – Product Specification – Product brief – Application notes –... - Page 9 Z8 Encore! 8K/4K MCU Evaluation Kit User Manual • CD-ROM • One or more RS-232 communication ports Introduction Preliminary UM015003-0603...
-
Page 10: Installation
Z8 Encore! 8K/4K MCU Evaluation Kit User Manual Installation Follow the directions in the Quick Start Guide for software installation and setup of the Z8 Encore! evaluation kit. Installation Preliminary UM015003-0603... -
Page 11: Z8 Encore! 8K/4K Evaluation Board
Introduction The Z8 Encore! 8K/4K evaluation board is an evaluation and prototyping board for the Z8 Encore! Z8 Encore! 8K/4K MCU. The board provides customers with a tool to evaluate features of Z8 Encore! 8K/4K MCU, and to start developing an application before building the hardware. -
Page 12: Features
2.7–3.6V operating voltage with 5V-tolerant inputs The Z8 Encore! 8K/4K MCU is member of a family of ZiLOG micro- controller products based upon the 8-bit eZ8 core CPU. The Flash in-cir- cuit programming capability allows for faster development time and program changes in the field. -
Page 13: Uart With Irda Endec
For further information on the Z8 Encore! family of devices, consult the product specification, P/N PS0197, available for download from www.zilog.com. UART with IrDA Endec The Z8 Encore! 8K/4K contains a fully-functional, high-performance UART with Infrared Encoder/Decoder (ENDEC), component U6. The... -
Page 14: Crystal Oscillator
Z8 Encore! 8K/4K MCU Evaluation Kit User Manual munication between the Z8 Encore! 8K/4K and IrDA transceivers. Infra- red communication provides secure, reliable, low-cost, point-to-point communication between PCs, PDAs, cell phones, printers and other infra- red enabled devices. Crystal Oscillator The evaluation board ships with an 18.432MHz Crystal Oscillator (Y1). -
Page 15: External Interface Headers Jp1 And Jp2
Z8 Encore! 8K/4K MCU Evaluation Kit User Manual External Interface Headers JP1 and JP2 The external interface headers, JP1 and JP2 contain no connectors when the board is shipped. The user can insert 0.1" space connectors of choice. Z8 Encore! 8K/4K Evaluation Board Preliminary UM015003-0603... -
Page 16: Schematics
Z8 Encore! Flash Microcontroller Development Kit User Manual Schematics This section includes schematics for the the Z8 Encore!™ 8K/4K Evalu- ation Board. Schematics P r e l i m i n a r y UM015003-0603... -
Page 17: Preliminary
Z8 Encore! 8K/4K MCU Evaluation Kit User Manual VCC_33V VCC_33V VCC_33V connector 2 22uF 0.01uF VCC_33V PC4_MOSI PC5_MISO PC3_SCK PC2_SS PC0_T1IN PA0_T0IN PA1_T0OUT PC1_T1OUT PA0_T0IN PA1_T0OUT VCC_33V PA3_CTS0 PA4_RXD0 PA5_TXD0 TEST GREEN 100K PA6_SCL PA7_SDA If Module is plugged onto the Dev Platform the local YELL RS232 interface is disabled by pin 50 of JP2 -DIS_232... -
Page 18: Preliminary
Z8 Encore! 8K/4K MCU Evaluation Kit User Manual VCC_33V PWR JACK RXE110 + C1 CONSOLE 0.1uF 0.1uF 100/10 0.1uF 0.1uF TXD0 CTS0 VCC_33V 0.1uF RXD0 VOUT VCC_33V T1IN T1OUT PA5_TXD0 PA5_TXD0 + C8 LT1086-3.3/TO220 T2IN T2OUT 100/10 0.1uF PA3_CTS0 DB9 Female PA3_CTS0 R1OUT R1IN...
