Part Identification ChartÑModel No. PFBE64490
R0999A
M6 x 16mm Screw (3)Ð4
Pulley Spacer (41)Ð2
16mm x 18.5mm Spacer (8)Ð2
M6 x 38mm Screw (4)Ð4
Leg Lever Spacer (50)Ð1
M6 Washer (30)Ð5
M6 x 63mm Screw (7)Ð1
M8 x 64mm Bolt (43)Ð1
M8 Washer (23)Ð2
M8 x 70mm Bolt (48)Ð1
M10 Washer (6)Ð5
M10 x 19mm Bolt (46)Ð1
M10 x 62mm Carriage Bolt (33)Ð8
M8 Nylon Locknut (13)Ð2
M10 x 68mm Bolt (34)Ð8
M10 Nylon Locknut (11)Ð20
M10 x 75mm Bolt (60)Ð1
M10 x 155mm Bolt (22)Ð1
5
