Understanding the Display and External PC Connections

Follow the schematic drawing, below, to hook up an external PC.
Note: Remember to disconnect the display from power, before you connect/disconnect it from the PC.
HDMI 1
Under Display Ports
PC Ports
DC-IN HDMI
INF8630eAG / INF8630AG Hardware Guide
HDMI 2 HDMI 3
VGA SDIF
HDMI OUT LAN
USB LAN AUDIO-OUT MIC-IN
HDMI 4 (MHL) VGA
TOUCH USB
PC-AUDIO
USB
