Summary of Contents for InFocus INF55WIN8
-
Page 3: Table Of Contents
Contents Declaration of Conformity ..................................3 Safety Considerations ..................................... 6 What’s Included...................................... 8 Setup ........................................9 Installing the Feet .................................... 9 Connecting to Other Devices ................................. 10 Connecting AC Power ..................................11 Turning the Monitor On/Off ................................. 12 Setting up the Wireless Mouse and Keyboard ............................. 13 Wireless Mouse ..................................... -
Page 5: Declaration Of Conformity
Adobe Systems Incorporated. HDMI logo and “High Definition Multimedia Interface” are registered trademarks of HDMI Licensing LLC. Vidtel is a trademark of Vidtel, Inc. InFocus, In Focus, and INFOCUS (stylized) are either registered trademarks or trademarks of InFocus Corporation in the United States and other countries. All other trademarks are the property of their respective owners. Any other trademarks, service marks, personal names or product names are assumed to be the property of their respective owners and are used only for reference. - Page 6 Canada This Class A digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe A est conforme à la norme NMB- 003 du Canada. INFORMATION FOR RADIO FREQUENCY DEVICES ONLY: This device complies with part 15 of the FCC Rules / RSS-210. Operation is subject to the following two conditions: (1) This device may not cause harmful interference and (2) this device must accept any interference received, including interference that may cause undesired operation.
- Page 7 Energy Star As an ENERGY STAR Partner, InFocus Corporation has determined that this product meets the ENERGY STAR guidelines for energy efficiency. ENERGY STAR® is a joint program of the U.S. Environmental Protection Agency and the U.S. Department of Energy aimed at saving money and protecting the environment through energy efficient products and practices.
-
Page 8: Safety Considerations
Safety Considerations Please read and follow all safety instructions provided below and on the monitor before connecting the monitor to a power source. Failure to comply with safety instructions may result in fire, electrical shock, or personal injury and may damage or impair protection provided by the equipment. - Page 9 Refer all service to qualified service personnel. Do not remove the cover or back. Servicing your own monitor can be dangerous to you and will void the warranty. • Only use replacement parts specified by InFocus. Unauthorized substitutions may result in fire, electrical shock or injury and may void the warranty. •...
-
Page 10: What's Included
(set of two) (set of six) *Not included for all countries. For setup purposes, a keyboard and mouse are recommended. For additional accessory options, such as stands, carts and wall mounts, see the InFocus website (www.infocus.com/store) or your local dealer. Page 8... -
Page 11: Setup
(The spacers are not used.) Using the handles on the back of the monitor, lift the monitor upright. For additional accessory options, such as stands, carts and wall mounts, see the InFocus website (www.infocus.com/store) or your local dealer. WARNINGS: •... -
Page 12: Connecting To Other Devices
Connecting to Other Devices A full range of digital and analog video inputs and audio source devices can be connected to the connection panels on the back and side of this monitor. Available jacks include: HDMI® (2), VGA, Component (RCA), S-Video, Composite, RS232, Audio in RCA (1 – R/L), Audio in 3.5mm (1), Audio Out (1 –... -
Page 13: Connecting Ac Power
Your monitor should only be operated from the power source indicated on the label. • Always unplug the AC power cord from the power outlet when you are not using your monitor for an extended period of time. INF55WIN8 Hardware Guide Page 11... -
Page 14: Turning The Monitor On/Off
Turning the Monitor On/Off Verify that the power cord is connected to a power outlet and that the power switch on the Bottom Connector Panel is ON. Press the Power button located on either: the remote the right side of the monitor or the back of the monitor on the PC box. -
Page 15: Setting Up The Wireless Mouse And Keyboard
+ and – ends of the batteries and sliding them in place. Replace the cover. Press the CONNECT button and hold it for one second to allow the key- board to bind with the dongle. INF55WIN8 Hardware Guide Page 13... -
Page 16: Using The Remote
Using the Remote The remote uses two (2) AAA batteries (not included). Install the batteries by removing the cover from the remote’s back, aligning the + and – ends of the batteries, sliding them in place and replacing the cover. To operate, point the remote at the monitor sensor at the bottom right-hand corner of the monitor. - Page 17 CONTRAST Back: Returns the user to the previous menu. BACK Left, Right, Up, Down Arrows and OK: Use these buttons to navigate through and make changes to the monitor and Onscreen Menu features. INF55WIN8 Hardware Guide Page 15...
-
Page 18: Using The Keypad
Info: n/a INFO Vol up: Increases the audio volume. VOL UP Vol down: Decreases the audio volume. Mute: Switches the audio on or off. MUTE Using the Keypad The keypad, located on the right-edge of the monitor, has the following buttons: Menu button: Turns the OSD menu on and off. -
Page 19: Osd (On-Screen Display) Menu System
GAMMA SELECTION UNDER SCAN SCAN MODE PROGRESSIVE SCAN CONVERSION FILM MODE AUTO IR CONTROL KEYBOARD CONTROL TILING HEAT STATUS DATE AND TIME SCHEDULE MONITOR ID DDC/CI ADVANCED OPTION RESET < > Adjust Enter Back Quit INF55WIN8 Hardware Guide Page 17... -
Page 20: Picture Menu
Picture Menu PICTURE BRIGHTNESS CONTRAST SHARPNESS BLACK LEVEL NOISE REDUCTION TINT COLOR COLOR TEMPERATURE 10000K COLOR CONTROL ADAPTIVE CONTRAST PICTURE MODE STANDARD PICTURE RESET < > Adjust Enter Back Quit Brightness: changes the intensity of the image. Range: 0-100. (Default 70.) Contrast: controls the degree of difference between the lightest and darkest parts of the picture and changes the amount of black and white in the image. -
Page 21: Screen Menu
Custom Zoom: allows the user to adjust zoom, horizontal zoom, vertical zoom, horizontal position and vertical position of the image. Aspect Ratio must be set to Custom to access this feature. Range: 0-100 for each item. Screen Reset: resets all Screen menu items to factory default settings. Options: Yes and No. INF55WIN8 Hardware Guide Page 19... -
Page 22: Audio Menu
Audio menu AUDIO BALANCE TREBLE BASS SPEAKER INTERNAL AUDIO SOURCE AUDIO RESET < > Adjust Enter Back Quit Balance: adjusts the balance between the left and right audio outputs. Range: 0-100. (Default 50.) Treble: adjusts higher pitched (treble) audio sounds. Range: 0-100. (Default 50.) Bass: adjusts lower-pitched (bass) audio sounds. -
Page 23: Pip Menu
Component S-video Composite INF55WIN8 Hardware Guide Page 21... - Page 24 When the Main picture is PC, the following configurations are available: Main Corner-to-Corner When the Main picture is not PC, the following configurations are available: Main Main Main Main Side-by-Side Picture-on-Picture Side-by-Side Corner-to-Corner Native Stretched To change the PiP source: Press remote PiP Input button. To swap the main and PiP sources: Press the remote’s PiP Swap button.
-
Page 25: Configuration 1
Blank Screen Type: defines the image displayed when the monitor is in Monitor mode (see Operation Mode above) and no source is detected. Options include: Black (default), Blue, White and (InFocus) Logo. Configuration Reset: resets all Configuration 1 and Configuration 2 menu items to factory default settings. Options: Yes and No. -
Page 26: Configuration 2
Configuration 2 CONFIGURATION 2 OSD TURN OFF INFORMATION OSD SLEEP TIMER OSD H POSITION OSD V POSITION MONITOR INFORMATION < > Adjust Enter Back Quit OSD Turn Off: controls how many seconds the OSD menu remains on the screen Range: 5-120 (seconds). (Default: 45) Information OSD: controls how many seconds the Information OSD remains on the screen. -
Page 27: Advanced Option
Range: 1-26. (Default; 1) DDC/CI: enables and disables DDC/CI communication. Options include: On (default) and Off. Advanced Option Reset: resets all Advanced Option menu items to factory default settings. Options: Yes and No. INF55WIN8 Hardware Guide Page 25... -
Page 28: Troubleshooting
Troubleshooting Symptom Possible Solutions No power • Verify the power cord is properly connected to the power outlet and to the monitor. Verify the power switch is ON and that the Power button on the remote or keypad has • been turned on (the front LED should be green). - Page 29 The monitor is in standby mode. Press the Power button on the remote or keypad. Green Green • The monitor is powered on. For Additional Troubleshooting Support, please contact: InFocus Corporation Technical Support 6am-5pm PST 877-388-8385 www.infocus.com/support INF55WIN8 Hardware Guide Page 27...
-
Page 30: Specifications
Specifications To read the latest specifications on this product, be sure to visit our support website at www.infocus.com/support, as specifications are subject to change. Size (viewable) 54.6” (138.7 cm diagonal) Resolution 1920 x 1080 Refresh rate 60 Hz Viewing angle ±89˚... - Page 31 59.2 x 103.6 x 34.8mm Weight ~68g excluding batteries Batteries Two (2) AAA alkaline Operating Voltage 2.0V~3.2VDC Power Consumption <8.5mA @3V Battery Life 150 working hours continuous operation Operating Distance 10M without signal disturbance and no direction limit INF55WIN8 Hardware Guide Page 29...
-
Page 32: Limited Warranty
If a hardware defect arises and a valid claim is received within the Warranty Period, at its op- tion and to the extent permitted by law, InFocus will either (1) repair the hardware defect at no charge, using new parts or refurbished... - Page 33 16 hours continuously per day with a minimum 8 hour period of continuous rest in the powered off state; or (m) if any InFocus serial number has been removed or defaced. In addition, LCD burn-in as a result of excessive display of static images on the product is not covered under the terms of this Limited Warranty.
- Page 34 InFocus will provide warranty service either (i) at an ASP location, where service is performed at the loca- tion, or the ASP may send the product to an InFocus repair service location for service, (ii) by sending you prepaid way bills (and if you...
- Page 35 InFocus may utilize a doorstep swap process, which involves an InFocus delivery person delivering the replacement product or CSR part to the Customer and picking up the defective product or part at the time of delivery for return to InFocus. Upon receipt of the replacement product or part, the original product or part becomes the property of InFocus and you agree to follow instructions, including arranging the return of original product or part to InFocus in a timely manner.
