Front Panel Ports

The front panel ports are located on the left side of the bottom front of the display. This table shows how to connect them.
Port
Connection instructions
name
Headset Connect a 3.5 mm headset to output audio. This will mute the internal speakers.
Mic Connect a 3.5 mm microphone or cable for audio input. Overrides audio from all other sources when connected.
PC USB Connect a USB 2.0 device to the OPS module.
Media
Connect a USB 2.0 device to the Internal Android.
USB
Touch Connect a USB A-B cable between this type B port and your computer to get touch control.
USB This works with front HDMI port.
HDMI Connect an HDMI cable from the display to an HDMI external device, such as a computer.
Page 14
PC USB MEDIA USB TOUCH USB
HDMI
