Diagnosis Report
(1) Clicking on the [Show Diagnosis Report] button displays detailed data such as product settings and
the diagnosis results while saving them in text format.
The Diagnosis Program performs "product presence/absence check", "driver file test", "board
setting test", and so on.
CAUTION
Before executing diagnosis report output, unplug the cable from the product.
(2) A diagnosis report is displayed as shown below.
DIO-3232LX-USB
* The name of the connected
product will be displayed.
DIO-3232LX-USB
* The name of the connected
product will be displayed.
DIO-3232LX-USB
Input port : 32Bit
Output port : 32Bit
will be displayed.
Click on [Show
Diagnosis Report].
2. Setup
21
