Step 4 Checking Operations with the Diagnosis
Program
Use the diagnosis program to check that the product and driver software work normally, thereby you
can confirm that they have been set up correctly.
What is the Diagnosis Program?
The diagnosis program diagnoses the states of the product and driver software.
It can also be used as a simple checker when an external device is actually connected.
Using the "Diagnosis Report" feature reports the driver settings, the presence or absence of the product,
I/O status, and interrupt status.
Using the Diagnosis Program
Starting the Diagnosis Program
Click [Diagnosis] on the Properties page to start the diagnosis program.
DIO-3232LX-USB
* The name of the connected
product will be displayed.
DIO-3232LX-USB
