2. Setup

Step 1 Setting the Hardware

This section describes how to set up the product and how to connect it to a PC.

Name of each parts

LED indicator

POWER Status

Interface

connector (CN1)

The above figure has installed the USB cable attachment.

Figure 2.1. Name of each parts (Front side)

Interface connector

USB TypeA

For PC

USB cable

attachment

USB port

[Type A

connector]

USB port

[mini B

connector]

+5VDC input

terminal

DIO-3232LX-USB
