StudioDesk MCDW04 Assembly Manual

Music and video commander desk

Advertisement

Quick Links

The Desk You Deserve
ASSEMBLY MANUAL
MCDW04 - MCDB04 Music Commander Desk
VCDW04 - VCDB04 Video Commander Desk
!
NOTE: In order to avoid injury or damages,
please do not try to assemble your desk alone.
The Commander is a heavy desk, which requires
at least two people to carry out assembly.
Please assemble on soft surface to avoid
scratches to the lacquer.
www.studiodesk.net

Advertisement

loading
Need help?

Need help?

Do you have a question about the MCDW04 and is the answer not in the manual?

Questions and answers

Summary of Contents for StudioDesk MCDW04

  • Page 1 The Desk You Deserve www.studiodesk.net ASSEMBLY MANUAL MCDW04 - MCDB04 Music Commander Desk VCDW04 - VCDB04 Video Commander Desk NOTE: In order to avoid injury or damages, please do not try to assemble your desk alone. The Commander is a heavy desk, which requires at least two people to carry out assembly.
  • Page 2 The Desk You Deserve Thank you for making StudioDesk your desk of choice! Before beginning assembly of your desk, let’s get familiar with the parts you have received in your package. Please match the corresponding numbers on this page with the drawings.
  • Page 3 Step One Insert dowels (12) into the holes as shown in the illustration. Use a rubber hammer if needed. Step Two Assemble parts together as shown in the illustration. Step Three Fix assembled parts together using metal corners (8) and M6 screws (10) as shown in the illustration.
  • Page 4 Step Five Once dowels are in place and boards sit tight to the leg, use metal corners (8) and M6 screws (10) to fix the middle section to the leg. Note! Turn the metal corner’s shorter edge downward Step Six Put strengthening board (2) in place.
