Setting up RS-232 projector control
Step 1
The MLC 206 must be configured before it can be used.
Start the software and configure the MLC.
The appearance of the screens varies depending on which accessories (control
modules and/or MediaLink Switcher) are connected to the MLC, as shown in the
following pictures.
MLC 206 without accessories
1. Load a projector driver: select the third tab, Controller (MLC) Config, and
select the Load Extron Driver button, as shown in the following illustration.
Choose the appropriate projector driver (filename.mll) from the on-screen
menu. If your projector brand and model are not listed, check the Extron Web
site to see if a new driver has been made and is available to download, or
contact an Extron representative.
MLC 206 with an MLS switcher, IRCM-DV+,
and RCM-SC connected
MLC 206 • Quick Start Guide 3
