MLC 206 Quick Start Guide, cont'd
MediaLink Controller (MLC 206) bottom panel connector pinouts
Extron Electronics, USA
1230 South Lewis Street
Anaheim, CA 92805
USA
714.491.1500
www.extron.com Fax 714.491.1517
8 MLC 206 • Quick Start Guide
A Modulated IR signal (carrier & signal)
B Power sense/display power detection
C Demodulated IR (signal only)
D Ground ( )
E +12VDC output
A Transmit (Tx)
B Receive (Rx)
Request to send (RTS)
C
D Clear to send (CTS)
E Ground ( )
1A Relay 1, pin A
1B
Relay 1, pin B
To/from
2A Relay 2, pin A
room control
2B Relay 2, pin B
equipment
3A Relay 3, pin A
3B Relay 3, pin B
A +12VDC output
B Ground ( )
C Control signal (IRCM)
Modulated IR (IR Link)
D
1 Input 1
2 Input 2
Input 3
3
To any contact closure-
4 Input 4
controllable Extron switcher
5 Input 5
6 Input 6
Receive (Rx)
A
To/from a MediaLink Switcher
Transmit (Tx)
B
or
Ground ( )
an external 12VDC, 1A power supply
+12VDC input
Not all wires must be connected for a
NOTE
given device or installation. Refer to
the appropriate manual for details.
Extron Electronics, Europe
Beeldschermweg 6C
3821 AH Amersfoort
The Netherlands
+31.33.453.4040
Fax +31.33.453.4050
© 2003 Extron Electronics. All rights reserved.
To IR Emitter(s),
an IR Broadcaster,
the projector's wired
remote port, and/or a
Display Power Sensor
To the
display/projector's
RS-232 port
To an IR Link
and/or MediaLink
Control Module(s)
