Power Management And The Payd Pin Pad - Moneris PAYD Pro Plus User Manual

Display Screen/Contactless Reader
8
•
WELCOME/BONJOUR screen displays while the PAYD
PIN pad is idle.
•
See Wave/tap: Contactless cards on page 58.
Magnetic Stripe Reader (the slot along the top of PAYD PIN
9
pad)
•
See Swipe: magnetic stripe cards on page 58.
Micro-USB port (located on the right side)
10
•
Plug in USB charging cable here (see Charging the PAYD
PIN pad below).
Power button (located on the right side)
•
For power functions, see the Power management and
11
the PAYD PIN pad section below.
•
For reset function, press and hold down until the
rebooting process starts.

Power management and the PAYD PIN pad

Charging the PAYD PIN pad
1. Plug the small end of USB cable into the PAYD PIN pad's micro-USB port
located on the side near the F4 key.
2. Plug the other end of the USB cable into a powered USB port. If you are
using a USB port on your computer, ensure the computer is turned on.
3. Wait while the PAYD PIN pad powers up.
4. When you see the TELIUM MENU screen, set the PAYD PIN pad aside, and
leave it to charge for 3 hours.
75
