Dahua A5A21M/CG9 User Manual

Dahua A5A21M/CG9 User Manual

5000 series gige large area scan industrial camera
Hide thumbs
Table of Contents

Advertisement

Quick Links

GigE Large Area Scan Industrial Camera
User Manual
V1.0.0
Dahua Technology Co., Ltd.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the A5A21M/CG9 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Dahua A5A21M/CG9

Summary of Contents for Dahua A5A21M/CG9

  • Page 1 GigE Large Area Scan Industrial Camera User Manual V1.0.0 Dahua Technology Co., Ltd.
  • Page 2 Foreword Abstract The document briefly describes 5000 series GigE Large Area Scan Industrial Camera, including product introduction, networking, basic parameters and applications for quick operation. Symbol Convention The following symbols may appear in this document, and their meanings are as follows：...

  • Page 3: Important Safety Instructions

    Important Safety Instructions Here is the proper use of the product and prevention of dangers as well as loss of property, etc. Be sure to follow the instructions when using.  Please do not place or install the device in the location with strong sunlight or near the heat-generating equipment, make sure the cover temperature is controlled bellow 60℃.
  • Page 4 Directory Foreword ............................II Important Safety Instructions ..................... III 1 Product Overview ........................5 1.1 Product Introduction ......................5 1.2 Product Features ........................5 1.3 Typical Networking ......................5 1.4 Main Technical Parameters ....................6 1.5 Spectral Curve ........................8 1.6 Environmental Requirements ....................

  • Page 5: Product Overview

    Product Overview Product Introduction 5000 series GigE large area scan camera adopts high-performance sensor chip and realizes real-time non-compressed image data transmission via GigE, which is compatible with any application development tool which meets GigE Vision and GenICam standard. Max transmission rate 1Gb/s can satisfy the requirements of transmission rate in most industrial applications.

  • Page 6: Main Technical Parameters

    Figure 1-1 Typical Networking Main Technical Parameters Main technical parameters of 5000 series GigE Large Area Scan Industrial Camera are as follow: Sheet 1-1 A5A21M/CG9 Technical Parameters 5000 Series 12MP GigE Mono/Color Area Scan Camera Sensor Model PYTHON 12K Sensor Type...
  • Page 7 5000 Series 12MP GigE Mono/Color Area Scan Camera DC power through Hirose connector with voltage range of Power Supply 12V~24V Power 12V≈9W Consumption -30 ℃ ～ +80 ℃ ; Storage Temperature: Operating Temperature Temperature: -30℃ ～ +50℃ Power/Weight Dimension/ 76mm × 76mm × 46mm(Not including the rear case Dimension Certification connectors)

  • Page 8: Spectral Curve

    5000 Series 12MP GigE Mono/Color Area Scan Camera Certification Power 12V≈9W Consumption Storage Temperature：-30℃～+80℃；Operating Temperature Temperature：-30℃～+50℃ 76mm × 76mm × 46mm(Not including the rear case Dimension connectors) Weight 450g Conforms to CE，FCC，UL，RoHS，GigE Vision V2.0 and Certification GenICam Software MV Viewer or GenICam and GigE Vision supported devices Spectral Curve The following spectral curve data are derived from the manual of the selected chip.
  • Page 9 Operating cover temperature：0℃～60℃.  Operating ambient humidity：20%～80% no condensation.  Storage temperature：-30℃～+80℃.  Storage humidity：20%～80% no condensation.   Please install the device in a stable location indoors, with enough heat dissipation space.  Please keep certain ventilation.

  • Page 10: Interface Description

    Interface Description Product Dimensions The product dimensions are as follows： Figure 2-1 76mm×76mm×46mm（Unit：mm） Interface Description The back of the device has two interfaces, the network interface and 12pin power as well as I/O...

  • Page 11: Network Interface

    interface, as shown below: Figure 2-2 76mm×76mm×46mm Interface Description 2.2.1 Network Interface Network interface, RJ45 Ethernet port, three-speed Ethernet 10M / 100M / 1000Mbps transmission interface for camera control, data transmission and power supply (POE function). It is best to use shielded twisted-pair Category 6 cable in order to ensure the transmission quality, as well as to prevent too much data retransmission and packet loss phenomenon.

  • Page 12: Electrical Specification

    Signal Description OPT_IN_GND Opto-isolated input ground OPT_OUT1 Opto-isolated output 1 OPT_OUT2 Opto-isolated output 2 OPT_OUT3 Opto-isolated output 3 OPT_OUT_GND Opto-isolated output ground Electrical Specification 2.3.1 Power Supply and Network Port Electrical Specifications Sheet 2-2 Power Supply and Network Port Electrical Specifications Parameter Description ；...

  • Page 13: Indicator Light Description

    Figure 2-3 Opto-isolated Input Circuit 2.3.2.2 Opto-isolated Output Sheet 2-4 Opto-isolated Output Voltage Description DC 30V Limit voltage: input voltage should not exceed this limit, otherwise it will cause damage to the device DC ＜3.3V I/O output may be wrong DC 3.3V～+24V I/O output safe operating voltage range The max continuous current of isolated I/O output is 50mA.
  • Page 14 Sheet 2-5 Indicator Light Description Status Indicator light status Note light quick Device booting. flashing IP is assigned, and the application Blue light slight software API is not connected to the brightness device. The application software API is Blue light high connected to the device, free mode, brightness...

  • Page 15: Product Installation

    Product Installation Installation is divided into hardware installation and application installation. Hardware Installation Before installation, please check the device whether there is any obvious damage, and confirm with the list of default accessories. 3.1.1 Default Accessories The list of default accessories is shown in Sheet 3-1. Sheet 3-1 Accessory List Accessory...

  • Page 16: Software Installation

    on-off devices, such as stepper motors. In particularly, do not route power cord and network cable with such devices in parallel because such devices have strong electro-magnetic radiation which is easy to couple to the camera's transmission line.  Shelter grounds of all devices must be connected together and take single point grounding. Multi-point grounding easily leads to voltage difference between devices which form circuits to induce couple electro-magnetic interference.
  • Page 17 Figure 3-1 Installation Completion...

  • Page 18: Network Settings

    Network Settings  Please make sure that GigE area scan camera is properly connected to the PC.  Please install the application in the PC. If have any problems, please refer to “3.2 Software Installation” for details. When the camera is well connected with cables, the application installed can detect the online camera. The camera can operate normally when the camera IP and the local computer IP are on the same network segment.
  • Page 19 Step2 IP Setting. Select the device you need to connect, then click . Configure a valid IP address for the detected device and make sure that the device IP is added to the same network segment of the local computer IP, as is shown in Figure 4-2. Click to save the settings after accomplishment.
  • Page 20 Figure 4-3 Successful Device Connection（Device Interface） Figure 4-4 Successful Device Connection（Property Interface） Sheet 4-1 Parameter Description Parameter Description Please refer to Sheet 4-2 for more details about the menu column.
  • Page 21 Parameter Description It is to detect the device list of all the online devices, which are GigE, USB and CameraLink. ：Refresh, click the icon and manually refresh the info of online device. ：It means the device is in a connectable state. ：It means the device is in a non-connectable state;...
  • Page 22 Parameter Description  ：Maximize the window.  ：Restore the window size downwards.  ：Minimize the window.  ：Close the application. ：It is to display all the combined parameter info. ：It is to combine all the displayed parameter info. Parameter visibility. Click according to your needs.
  • Page 23 Menu Note Event notice It includes device parameter update, event message channel and Event pull stream cache, etc. Save picture Save the video stream data as picture file. Picture Save current picture Save the video stream data of last frame as picture file. Connection control It is to set the time of connection timeout and detection interval.

  • Page 24: Main Function Description

    Main Function Description This chapter mainly introduces function parameters related to industrial camera. Please refer to "Properties" interface in MV Viewer for details of parameter information.  Industrial camera supports three user levels which are Beginner, Expert and Guru. The parameter items in corresponding property interface of each level are slightly different.

  • Page 25: Device Control

    Functions of ISP module for different image formats are shown in Sheet 5-1: Sheet 5-1 Functions of ISP Module for Different Image Formats Format Exposure Gain Blacklevel WhiteBalance Gamma Mono Bayer RGBxxx YUVxxx BalanceWhiteAuto to Off; select Red, Disable BlackLevelAuto Set GainRaw to 1 Green or Blue in Gamma...
  • Page 26 Figure 5-1 Device Control Sheet 5-2 Device Control—Parameter Explanation Parameter Explanation The device type defined by GigE Vision. DeviceType The scan type of the sensor: area scan / line scan. DeviceScanType DeviceVendorName Device vendor name. DeviceModelName Device model name. DeviceManufacturerInfo Device manufacturer info.

  • Page 27: Imageformatcontrol

    Parameter Explanation to GigE Vision protocol. This column can automatically recognize the protocol that comes with the camera, which can’t be changed. The major version of the transport layer protocol that the DeviceTLVersionMajor device is compatible with. The minor version of the transport layer protocol that the DeviceTLVersionMinor device is compatible with.
  • Page 28 Figure 5-2 Image Format Control Sheet 5-3 Image Format Control – Parameter Explanation Parameter Explanation SensorWidth Sensor raw image width in pixels. SensorHeight Sensor raw image height in pixels. Maximum width of the image (in pixels), which will be affected by WidthMax decimation, etc.

  • Page 29: Acquisitioncontrol

    BayerRGxxx and BayerGBxxx. PixelFormat Image output format. Different models support different formats. PixelSize Total size in bits of a pixel of the image. Type of color filter that is applied to the image in the current image output format. PixelColorFilter Only the color camera has this property.
  • Page 30 Figure 5-3 Acquisition Control Sheet 5-4 Acquisition Control - Parameter Explanation Parameter Explanation Image acquisition mode：  SingleFrame: acquires one frame at a time and stops to capture frames automatically when finished. AcquisitionMode  MultiFrame: acquires frames specified AcquisitionFrameCount stops capture frames automatically when finished.
  • Page 31 Parameter Explanation The frame rate set in AcquisitionFrameRate is valid only when AcquisitionFrameRateEnable is True. AcquisitionFrameRateEnable If the frame rate is set beyond the max frame rate (ResultingframeRateAbs) in the current mode, the actual frame rate of the camera is ResultingframeRateAbs, not the value set by AcquisitionFrameRate.

  • Page 32: Digitaliocontrol

    Parameter Explanation Some models do not support TriggerWidth mode. ExposureTime Exposure time. Exposure automatically.  Off means the function is disabled. You can set exposure time in ExposureTime with a range of 0us～1000000us.  Once means the camera can modify the exposure time once ExposureAuto according to the ambient brightness.

  • Page 33: Eventcontrol

    Sheet 5-5 Digital IO Control - Parameter Explanation Parameter Explanation LineSelector Selects the external IO line for configuration. LineMode Configures the output mode of selected IO Line：Input/Output. Controls the selected physical input or output line signal inversion, LineInverter True is for the signal to invert, False for the signal not to invert. Indicates the current status of the selected physical input or output LineStatus line.

  • Page 34: Analogcontrol

    Event Control Figure 5-5 Sheet 5-6 Event Control - Parameter Explanation Parameter Explanation Event setting. Selects the type of event, including：  ExposureEnd（Exposure end event） FrameTrigger （ Event for frame trigger sending signal to  EventSelector sensor）  FrameStart（Receiving frame trigger event） ...
  • Page 35 Parameter Explanation different types and the default value is 1. The analog gain is preferentially enabled. BlackLevelSelector is used to select the black balance channel. BlackLevelSelector BlackLevel is used to eliminate the impact of Sensor’s dark current. The dark BlackLevel current is a phenomenon that the image brightness is a value greater than 0 when it is all black.

  • Page 36: Lutcontrol

    LUTControl In this property, you can stretch and highlight the gray-level range of the region of interest. The operation applies to linear curve as well as customized mapping curve, as shown in Figure 5-7; please refer to Sheet 5-8 for detailed parameter settings. ...
  • Page 37 Figure 5-8 Transport Layer Control...
  • Page 38 Sheet 5-9 Transport Layer Control - Parameter Explanation Parameter Explanation The number of bytes transferred for each image or PayloadSize chunk on the stream channel. GevActiveLinkCount The number of logical channels currently connected. The number of network ports on the device. The value GevInterfaceSelector starts at 0, so the value is 0.
  • Page 39 Parameter Explanation and IP will be in static mode after the device is powered The three IP precedence relationships are: static IP> DHCP> LLA. GevCurrentIPAddress IP address of the current device. GevCurrentSubnetMask Subnet mask of the current device. GevCurrentDefaultGateway Default gateway of the current device Displays how the current IP address is allocated, LLA, GevIPConfigurationStatus DHCP or static IP.
  • Page 40 Parameter Explanation Controls application’s access to the camera.  ExclusiveAccess: application connected to the camera can modify the registers. GevCCP  ControlAccess: application connected to the camera can only read the registers but can’t modify them. Displays the UDP source port of the application GevPrimaryApplicationSocket connected to this camera.

  • Page 41: Usersetcontrol

    UserSetControl In this property, you can save or load the parameter scheme set by user and set the default parameter configuration when opening the client, as shown in Figure 5-9; please refer to Sheet 5-10 for detailed parameter settings. Figure 5-9 User Set Control Sheet 5-10 User Set Control - Parameter Explanation...

  • Page 42: Counterandtimercontrol

    Figure 5-10 Color Transformation Control Sheet 5-11 Color Transformation Control - Parameter Explanation Parameter Explanation Selects which color transformation module to configure, currently ColorTransformationSelector supports RGBtoRGB and RGB to YUV. Enables the color transformation module. RGBtoRGB and ColorTransformationEnable RGBtoYUV are separately. ColorTransformationValueSelector Selects enhancement coefficients.

  • Page 43: Ispcontrol

    Parameter Explanation Selects the counter which needs to configure：Counter0 or Counter1. CounterSelector If Counter0 is selected，CounterEventSource displays FrameTrigger. If Counter1 is selected，CounterEventSource displays FrameStart. Selects the signal source to reset the counter：non-reset Off、software signal CounterResetSource reset SoftwareSignal0 and hardware signal reset Line1. Select the events that will be the source to increment the Counter ：...
  • Page 44 Sheet 5-13 ISP Control - Parameter Explanation Parameter Explanation Sharpness. Sharpness Selects On in SharpnessEnable to enable the sharpness adjustment. SharpnessAuto Adjusts the sharpness.  When SharpnessAuto is set as On, the camera can adjust the sharpness automatically and displays in Sharpness. SharpnessEnable ...
  • Page 45 You can solve problems that you may encounter with following instructions: Application fails to discover the device. Reason analysis：  The camera fails to boot up normally.  Connection of network cable is abnormal.  The camera and the client are not on the same LAN. Solutions：...
  • Page 46 It fails to enable external trigger. Reason analysis：  External trigger connection is wrong.  It fails to select external trigger in trigger mode. Solutions： Select correct trigger mode and make sure external connection is correct. The image is reverse when the client software checks image. Reason analysis: ...

  • Page 47: Cleaning And Maintenance

    Cleaning and Maintenance This chapter mainly introduces cleaning and replacement of color filter. We have installed a fully transparent protective glass for the mono camera with the main purpose to prevent dust falling on the surface of image sensor. The color camera is equipped with a low-pass filter that cuts off to the near-infrared band.
  • Page 48 【社会 的安全我们 的责 任】 SOCIALSECURITYISOURRESPONSIBILITY Dahua Technology Co., Ltd. Address：No.1187 BinAn Road, Binjiang District, Hangzhou, P.R.C Postcode：310053 Service Hotline：400-672-8166 Website：www.dahuatech.com...
