AES-100
ADSL-Ethernet Switch
February 2001
User's Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AES-100 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ZyXEL Communications AES-100

Summary of Contents for ZyXEL Communications AES-100

  • Page 1 AES-100 ADSL-Ethernet Switch February 2001 User’s Guide...
  • Page 2 ZyXEL Communications Corporation. Published by ZyXEL Communications Corporation. All rights reserved. Disclaimer ZyXEL does not assume any liability arising out of the application or use of any products, or software described herein.
  • Page 3 AES-100 ZyXEL Limited Warranty ZyXEL warrants to the original end user (purchaser) that this product is free from any defects in materials or workmanship for a period of up to two (2) years from the date of purchase. During the warranty period, and upon...

  • Page 4: Customer Support

    AES-100 Customer Support If you have questions about your ZyXEL product or desire assistance, contact ZyXEL Communications Corporation offices worldwide, in one of the following ways: Contacting Customer Support When you contact your customer support representative, have the following information ready: ♦...
  • Page 5 Customer Support..................................iv Table of Contents..................................v List of Figures ....................................viii List of Tables ....................................viii Preface ......................................ix Chapter 1 Getting to Know the AES-100..........................1-1 Overview of the AES-100...........................1-1 Example MTU Application..........................1-1 Chapter 2 Hardware Installation ............................2-1 Unpacking the AES-100..........................2-1 Additional Installation Requirements ......................2-1 Front Panel ..............................2-1...
  • Page 6 AES-100 3.4.6 Config Save Command........................3-3 3.4.7 Exit Command ...........................3-3 Chapter 4 ADSL Configuration.............................4-1 ADSL standards ............................4-1 Configured vs. Actual Speed........................4-1 ADSL Commands ............................4-1 4.3.1 Config Save Command........................4-1 4.3.2 Disable Port Command........................4-1 4.3.3 Disable Ports Command ........................4-2 4.3.4 Enable Port Command ........................4-2 4.3.5...
  • Page 7 AES-100 Chapter 6 Firmware Update ..............................6-1 Index......................................A Customer Support...
  • Page 8 AES-100 List of Figures Figure 1-1 AES-100 Building Deployment Example ........................1-2 Figure 2-1 AES-100 Front Panel ..............................2-2 Figure 2-2 Rear Panel..................................2-3 Figure 5-1 SNMP Management Model ............................5-2 List of Tables Table 2-1 Front Panel Ports .................................2-2 Table 2-2 Front Panel Indicators ..............................2-2...
  • Page 9 Related Documentation Support Notes More detailed information about the AES-100 and examples of its use can be found in the Support Notes accessible through the ZyXEL web pages at www.zyxel.com. ZyXEL Web Page and FTP Server Site You can access release notes as well as firmware upgrades at ZyXEL web and FTP sites.

  • Page 11: Chapter 1 Getting To Know The Aes-100

    A tenant connects a PC to the phone line in a unit using an ADSL modem. The other end of the phone line is connected to a port on the AES-100. The AES-100 aggregates the traffic from the tenants to the Ethernet port and forwards it to a router.
  • Page 12 AES-100 Figure 1-1 AES-100 Building Deployment Example Getting to Know AES-100...

  • Page 13: Chapter 2 Hardware Installation

    This chapter shows you how to install the AES-100 hardware. Unpacking the AES-100 Before installing, check if all the components of the AES-100 package are included. Observe the safety rules carefully when you are making the connections. Additional Installation Requirements In addition to the contents of the package, you need additional hardware and software components before you install and use your product.

  • Page 14: Front Panel Ports

    Table 2-2 Front Panel Indicators INDICATOR DESCRIPTION The SYS LED indicates the operational status of the AES-100. It is steadily on when power is applied and the AES-100 is functioning normally. LINK The LINK LED is steadily on when the LAN port link is up.

  • Page 15: Rear Panel

    The following figure shows the rear panel of the AES-100. Connect one end of the power cord to the receptacle labeled AC INPUT on the rear panel of your AES-100 and the other end to the power outlet. Please make sure that no objects obstruct the smooth free-flowing operation of the fan (to the left of the power receptacle).

  • Page 17: Chapter 3 Software Configuration

    This section describes the general software configuration of the AES-100. Command Line Interface The AES-100 uses text command lines as the user interface for software configuration. Before discussing the details of configuration, the rules of the commands are listed below.

  • Page 18: Command Structure

    AES-100 Command Structure The system uses a two-level command structure. The commands related to one subsystem are grouped under a primary command of that subsystem, e.g., to configure the ADSL parameters, you must first enter the ADSL subsystem by entering the command.

  • Page 19: Restart Command

    AES-100 3.4.3 Restart Command Syntax: restart command instructs the system to perform a warm start, i.e., restarting the system without turning restart the power on and off. 3.4.4 Passwd Command Syntax: passwd command changes the management password. The management password is used for authentication passwd during console or telnet login.

  • Page 21: Chapter 4 Adsl Configuration

    ADSL ports. ADSL standards The AES-100 supports both the G.lite and the G.dmt standards. G.lite is intended to minimize the cost for the consumer market and limits the speed to 1.5 Mbps (megabits per second) downstream (AES-100 to user) and 512 Kbps upstream (user to AES-100), while G.dmt support up to 8 Mbps downstream and 2 Mbps upstream.

  • Page 22: Disable Ports Command

    AES-100 where <port number> = port number, from 1 to 8 command forcibly disables the specified ADSL port. disable port The factory default of all ports is disabled. A port must be enabled before data transmission can occur. An enabled but disconnected ADSL port generates more heat than an operating port. To minimize heat generation and to enhance reliability, remember to disable a port when it is not in use.

  • Page 23: Linedata Command

    AES-100 4.3.6 Linedata Command Syntax: linedata <port number> where <port number> = port number, from 1 to 8 command shows the line bit allocation of an ADSL port. linedata An example is shown next. 192.168.1.1 adsl> linedata 7 DS carrier load: number of bits per symbol(tone):...

  • Page 24: Lineperf Command

    AES-100 192.168.1.1 adsl> lineinfo 7 Current Operating Modes: Data Mode: ATM Service Type in operation: G.DMT Number of Channels (Down/up stream): 1/1 Downstream Framing Structure Active down/up stream rate option : 1/1 TRELLIS operation mode is : ON Current Connection detail:...

  • Page 25: Linerate Command

    AES-100 192.168.1.1 adsl> lineperf 7 nfebe-I/nfebe-ni : 0/0 ncrc-I/ncrc-ni : 0/0 nfecc-I/nfecc-ni : 0/0 nfec-I/nfec-ni : 0/0 nblks-ds/nblks-us : 120878/120878 nsec-ds/nsec-us : 2060/2060 n-eb-ds/n-eb-us : 0/0 n-bbe-ds/n-bbe-us : 0/0 n-es-ds/n-es-us : 0/0 n-ses-ds/n-ses-us : 0/0 non-ses-blks-ds/non-ses-blks-us : 120878/120878 n-uas-ds/n-uas-us : 0/0...

  • Page 26: List Port Command

    AES-100 LS0 upstream rate 512 Kbps LS1 upstream rate 0 Kbps Down/up stream Margin : 31/22 dB Down/up stream Attenuation 0/ 0 dB Attainable Dwon/up stream Rate : 11456/ 1344 Kbps These results contain the current downstream and upstream operating values (SHOWTIME) for the requested line, the latest available downstream and upstream margins, channel attenuation and the maximum attainable rate.

  • Page 27: Show Port Command

    ADSL port. Note that the upstream speed must be less than or equal to the downstream speed. The mode parameter specifies the standard that this port is allowed. When set to auto, the AES-100 follows whatever mode is set on the other end of the line. This mode is allowed but strongly discouraged, since the user equipment may or may not have been configured properly.

  • Page 29: Chapter 5 Ip Configuration

    2. Have a complete diagram showing the whole network. 3. Record the IP parameters assigned to the equipment in your network. Setting IP address To set the IP address and the subnet mask of the Ethernet port of the AES-100, use the following command sequence: 1. 192.168.1.1> ip 2.

  • Page 30: Management By Telnet

    Management by Telnet After you have set up the IP parameters and connect the AES-100 to the network, you can manage it remotely with telnet. You can use any telnet client that is convenient to you. The configuration procedures with telnet are exactly the same as those using the direct connection via the console port.

  • Page 31: Snmp Access Configuration

    An SNMP managed network consists of two main components: agents and a manager. An agent is a management software module that resides in a managed device (AES-100). An agent translates the local management information from the managed device into a form compatible with SNMP. The manager is the station through which network administrators perform network management functions.

  • Page 32: Snmp Trap Configuration

    This command shows the allowed access. 5.3.2 SNMP Trap Configuration The AES-100 uses the SNMP trapping facility to proactively report unusual events to one or more trap servers. To configure the trap parameters, use the commands in the IP subsystem. After configuring the...

  • Page 33: General Ip Commands

    AES-100 Trap Delete Command Syntax: snmp trap delete <community> <IP addr> [<port>] This command deletes a trap destination. The arguments are the same as the command. snmp trap add Trap Flush Command Syntax: snmp trap flush This command deletes all trap destinations.

  • Page 34: Route Manipulating Commands

    Route Manipulating Commands If the AES-100 needs to talk to a host not on the local Ethernet, then it must have routing information in order to forward its packets to the right gateway. Generally speaking, you only need a default route for all destinations, however, the route manipulating commands are available for you to manage any routes.

  • Page 35: Statistics Command

    AES-100 routes This command shows all the IP forwarding routes. 5.4.4 Statistics Command Syntax: stats <sub cmd> This command shows the statistics for the traffic of the type specified by the sub-command. Statistics are available for the following traffic type: ARP, ICMP, IP, raw, TCP and UDP.
  • Page 37 On the AES-100, wait for the update to complete and then restart AES100. Extreme caution: Do not turn off the AES-100 when the updating process is in progress, as it may corrupt the firmware and make your AES-100 unusable.
  • Page 39 IP address, 5-2 ACTIVE, 4-3 default route, 5-1 Actual Speed, 4-1 Disable Port Command, 4-1 ADSL standards, 4-1 Disable Ports Command, 4-2 AES-100, ix Disclaimer, ii Aggregates traffic, 1-1 Downstream (ds), 4-5 auto, 4-7 Enable Port Command, 4-2 Building Deployment, 1-2...
  • Page 40 AES-100 parity bytes per codeword, 4-4 Passwd Command, 3-3 Help Facility, 3-2 Password, 5-3 Ping Command, 5-5 interleave delay, 4-4 Rear Panel, 2-3 line bit allocation, 4-3 Related Documentation, ix line operating values, 4-3 relay, 5-6 line performance counters, 4-4...
  • Page 41 AES-100 upstream (us), 4-5 Uptime Command, 3-2 Telnet, 5-2 User port, 2-3 Terminal Emulation, 2-1, 3-1 TFTP, 6-1 timeout, 5-6 Vendor ID, 4-4 Trap Add Command, 5-4 Version Command, 3-2, 5-7 Trap Configuration, 5-4 Version Number, 4-4 Trap Delete Command, 5-5...
