Intel® Server Board S2600WF Product Family Technical Product Specification
2.1

Server Board Family Feature Set

Table 2 lists the server board product family feature set.
Table 2. Intel® Server Board S2600WF product family feature set
Intel® Server
Board Feature
Processor • (2) – LGA3647-0 (Socket P) processor sockets
• Supports (1) or (2) processors from the Intel® Xeon® processor Scalable family (Platinum, Gold, Silver, and
Bronze). Note: Previous generation Intel® Xeon® processors are not supported.
• Maximum supported Thermal Design Power (TDP) of up to 205 W (board only)
• Note: Intel® Server Systems based on this server board family may support a lower maximum Thermal
Design Power (TDP). See the appropriate Intel® System TPS for maximum supported TDP.
Memory • (24) – total DIMM slots
o (12) – DIMM slots per processor, (6) – memory channels per processor
o (2) – DIMMs per channel
• Registered DDR4 (RDIMM), Load Reduced DDR4 (LRDIMM)
• Memory capacity
o Up to 1.5 TB for Gold and Platinum CPUs
o Up to 768 GB for Silver and Bronze CPUs
• Memory data transfer rates
o Up to 2666 MT/s at (1) and (2) DIMMs per channel (dependent on processor)
• DDR4 standard voltage of 1.2 V
Intel® C62x Series Intel® C624 Chipset
Chipset
Intel® Quick Assist No
Technology
Intel® Omni-Path Yes
Fabric
Onboard LAN Dual Port RJ45 10 GbE
OCP Module • Dual Port 10Gb RJ45 –
Support iPC 557T2OCPG1P5
• Dual Port SFP+ –
iPC 527DA2OCPG1P5
Intel® Integrated Yes
SAS Module
Onboard PCIe* • (4) – OCuLink connectors
NVMe
• Intel® VMD support
• Intel® RSTe/Intel® VROC
support (accessory option)
S2600WFT
Intel® C624 Chipset
No
Yes
No
• Quad Port 1Gb RJ45 –
• Quad Port SFP+ –
• Dual Port 10Gb RJ45 –
• Dual Port SFP+ –
Yes
• (4) – OCuLink connectors
• Intel® VMD support
• Intel® RSTe/Intel® VROC
S2600WF0
iPC I357T4OCPG1P5
iPC X527DA4OCPG1P5
iPC X557T2OCPG1P5
iPC X527DA2OCPG1P5
support (accessory option)
S2600WFQ
Intel® C628 Chipset
Yes
Yes
No
• Quad Port 1Gb RJ45 –
iPC I357T4OCPG1P5
• Quad Port SFP+ –
iPC X527DA4OCPG1P5
• Dual Port 10Gb RJ45 –
iPC X557T2OCPG1P5
• Dual Port SFP+ –
iPC X527DA2OCPG1P5
Yes
• (2) – OCuLink connectors
• Intel® VMD support
• Intel® RSTe/Intel® VROC support
(accessory option)
17
