Tektronix RSA6100A Series Service Manual page 91

Replaceable parts list
Fig. & index Tektronix part
number number
5- - 6- - 1 671-5898-00
5- - 6- - 2 671-5907-00
5- - 6- - 3 211-1050-00
5- - 6- - 4 200-4962-00
5- - 6- - 5 200-4961-00
5- - 6- - 6 407-5181-00
5- - 6- - 7 174-5102-00
5- - 6- - 8 174-5103-00
5- - 6- - 9 211-0408-00
5- - 6- - 10 174-5090-00
5- - 6- - 11 039-0177-00
5- - 6- - 12 174-5091-00
5- - 6- - 13 174-5099-00
5- - 6- - 14 174-5101-00
5- - 6- - 15 174-5088-00
5- - 6- - 16 174-4791-00
5- - 6- - 17 211-0450-00
5- - 6- - 18 174-5106-00
5- - 6- - 19 174-5104-00
RSA6100A Series Service Manual Serial Numbers B020000 and Above
Serial no. Serial no.
effective discont'd
Qty
1
1
8
1
1
1
1
1
2
1
1
1
1
1
1
1
4
1
1
Name & description
CIRCUIT BD ASSY; REALTIME I/Q OUTPUT, (OPT. 05 ONLY)
CIRCUIT BD ASSY; RTT/DPSA BOARD
SCREW,MACHINE; 6- - 32 X 0.312 L,PNH,STL CAD PLT,T15,
COVER; REAR PANEL,OPTION(I&Q OUT,IF OUT); SAFETY CONTROLLED
(OPT. 05 ONLY)
COVER; REAR PANEL,OPTION(BLANK); SAFETY CONTROLLED
(ALL EXCEPT OPT. 05)
BRACKET, GROUNDING (LAN AND PS/2)
CA ASSY,SP; DISCRETE,SLOT PC TO DIG INTERFACE 15 PIN VGA,2X7
HEADER,0.100; SAFETY CONTROLLED
CA ASSY,SP; LAN,TW PAIR,MEGABIT LAN,RJ45,SLOTPC TO DIG INTF; SAFETY
CONTROLLED
SCR, ASSY, WSHR; 4- - 40 X 0.250, PNH, 410 SS PASSIVATED, T- - 10 TORX DR, SEMS
CA ASSY,PWR; DISCRETE,DIG INTERFACE,2X6,20AWG; SAFETY CONTROLLED
PROCESSOR MODULE; PCI 6881 WITH 1 GB RAM MODULE INSTALLED, SAFETY
CONTROLLED
CA ASSY,SP; IDC,RIBBON,FANOUT - - 4 SLOTPC TO DIG INTF 2X22,2MM; SAFETY
CONTROLLED
CA ASSY,SP; DISCRETE,LVDS VIDEO SLOTPC TO DIG INTF 2X20,1.25MM; SAFETY
CONTROLLED
CA ASSY,SP; IDC,RIBBON,AUDIO SLOTPC TO DIG INTERF,2X5,2MM; SAFETY
CONTROLLED
CA ASSY,SP; CRIMP,DISCRETE,PS/2,SLOT PC TO DIG INTF,1X5,2MM; SAFETY
CONTROLLED
CA ASSY,SP; RIBBON,IDC,28 AWG,7.0 L,
SCREW, MACHINE; 2.5MM X 0.45 X 6MM, PNH POZ DR, 410 SS PASSIVATED,
PHILIPS, (OPT. 05 ONLY)
CA ASSY,SP; IDC,TW FLAT,I & Q OUTPUT TO REAR PANEL,50 POS; SAFETY
CONTROLLED, (OPT. 05 ONLY)
CA ASSY,RF,FLEX- - COAX; IF OUT TO REAR PANEL,SMB,BNC; SAFETY
CONTROLLED, (OPT. 05 ONLY)
Replaceable Parts
5- 11
