Replaceable Parts
RF control, 15- - pin ribbon
cable to bulkhead
connector on chassis
3
4
Cable dress
RF interface
board
2
2
RF interface
1
board
RF deck
Instrument front
RF power, 60- - pin ribbon
cable to bulkhead
connectoron chassis
Figure 5- 15: RF interface board and cables
5- 24
RSA6100A Series Service Manual Serial Numbers B020000 and Above
