Dynojet Power Commander V Installation Instructions Manual page 6

FIG.J
FIG.K
PCV
FIG.L
PCV
I11-012.01 www.powercommander.com
14 Unplug the stock wiring harness from the rear fuel injector as shown in
Figure J.
stock
15 Attach the connectors with the yellow colored wires from the PCV harness to
the rear fuel injector and stock harness as shown in Figure K.
PCV
16 Locate the ignition coil connector for the rear cylinder below the base of the
radiator as shown in Figure L.
2012-2014 Arctic Cat Wildcat - PCV - 6
