Dynojet Power Commander V Installation Instructions Manual page 5

FIG.G
FIG.H
FIG.I
I11-012.01 www.powercommander.com
coil
10 Locate the front ignition coil on the rear of the firewall in front of the engine as
shown in Figure G.
11 Attach the connectors from the PCV harness with the green paired wires to
the stock front coil and stock wiring harness as shown in Figure H.
12 Unplug the stock wiring harness from the throttle position sensor.
13 Attach the connectors from the PCV harness to the stock throttle position
sensor and stock harness as shown in Figure I.
The throttle position sensor connector is difficult to access. Figure I was taken
from underneath the vehicle, looking up at the throttle body.
2012-2014 Arctic Cat Wildcat - PCV - 5
