Dynojet POWER COMMANDER V Installation Instructions
For kawasaki kx450f 2009
Hide thumbs
Also See for POWER COMMANDER V:
- Installation instructions manual (9 pages) ,
- Installation manual (9 pages) ,
- Installation instructions and owner's manuals (8 pages)
Advertisement
Quick Links
2009 Kawasaki KX450F
Installation Instructions
PLEASE READ ALL DIRECTIONS BEFORE STARTING INSTALLATION
17-002 www.powercommander.com
2191 Mendenhall Drive
North Las Vegas, NV 89081
Parts List
1
Power Commander
1
USB Cable
1
CD-ROM
1
Installation Guide
2
Power Commander Decals
2
Dynojet Decals
1
Zip tie
The ignition MUST be turned
OFF before installation!
YOU CAN ALSO DOWNLOAD THE
POWER COMMANDER SOFTWARE AND
LATEST MAPS FROM OUR WEB SITE AT:
WWW.POWERCOMMANDER.COM
(800) 992-4993
www.powercommander.com
2009 Kawasaki KX450F PCV - 1
Advertisement
Related Manuals for Dynojet POWER COMMANDER V
Summary of Contents for Dynojet POWER COMMANDER V
- Page 1 USB Cable 2009 Kawasaki KX450F CD-ROM Installation Guide Installation Instructions Power Commander Decals Dynojet Decals Zip tie The ignition MUST be turned OFF before installation! YOU CAN ALSO DOWNLOAD THE POWER COMMANDER SOFTWARE AND LATEST MAPS FROM OUR WEB SITE AT: WWW.POWERCOMMANDER.COM...
- Page 2 Do NOT connect anything to this port unless screw. Make sure to reinstall the rubber plug. instructed to do so by Dynojet. It is used to transfer crank trigger data from one module to NOTE: If you tin the wires with solder it will another.
- Page 3 FIG. A Remove the seat, fuel tank and front number plate. Secure the PCV to the stock ECU using the supplied zip tie (Fig. A) Route the PCV harness to the left side of the frame following the throttle cable. FIG.
- Page 4 FIG. D Unplug the Throttle Position Sensor harness (Fig. D). This connector is lo- Unplug TPS cated behind the throtttle body and is a WHITE 3 pin connector. It is best accessed from the right side of the bike. Figure D was taken from the left side of the bike, between the frame and air box.
