1: SGI InfiniteStorage NEXIS 2000 Quick Start
Multi-pin adapter
Chassis rail end
and bracket
Slide extension
Alignment tab
release
(3 per rail)
Component release
lever
Figure 1-17
Data Manager Slide Rails
20
007-4988-001
