Summary of Contents for Escea EP1350
- Page 1 Installation Instructions and User Guide EP1350 Escea Outdoor Fire Table For the latest documentation, visit www.escea.com or www.escea.com.au...
- Page 2 Warranty Repair and Annual Servicing Warranty repair work must be carried out by a suitably qualified person. Any shortcomings in the appliance will be the responsibility of the installer. Escea will not be accountable for any such failings or their consequences.
- Page 3 WARNING FAILURE TO FOLLOW THESE INSTRUCTIONS COULD RESULT IN DEATH, SERIOUS BODILY INJURY, AND/OR PROPERTY DAMAGE. FAILURE TO FOLLOW THESE INSTRUCTIONS MAY ALSO VOID YOUR FIRE INSURANCE AND/OR WARRANTY. A LIT FIRE MUST NEVER BE LEFT UNATTENDED. THE FIRE TABLE MUST ONLY BE USED FOR COOKING/HEATING AS INTENDED. MAINTAIN AND OPERATE THE FIRE TABLE IN ACCORDANCE WITH THESE INSTRUCTIONS.
-
Page 4: Table Of Contents
Installation Process and Product Details Product Description Product Dimensions Safety Clearances to Combustibles Clearances to Combustible Surfaces Assembling and Installing the Fireplace Installation Location Platform Minimum Requirements Placing the Appliance Using the Weather Cover Burning Guide Fuel Selection Starting the Fire Loading the Fire Extinguishing the Fire Cooking Guide... -
Page 5: A Installation Process And Product Details
Installation Process and Product Details Product Description The EP1350 is an outdoor fire table with the ability to transform seamlessly from a cooking appliance into a fire table. It is a freestanding structure that is not to be installed into a cavity. -
Page 6: Safety Clearances To Combustibles
Safety Clearances to Combustibles Clearances to Combustible Surfaces The EP1350 outdoor fire table is installed as a freestanding structure. The following clearances to combustible materials must be maintained to ensure safe operation. Warning: Never hang any combustible materials on, above, or around the fireplace. -
Page 7: Assembling And Installing The Fireplace
Assembling and Installing the Fireplace Installation Location The EP1350 is an outdoor fire table that is installed as a freestanding structure. Locate the fire away from windy areas for best performance. Platform Minimum Requirements The platform should be stable, level, and suitable to support the weight of the fire table. -
Page 8: C3 Placing The Appliance
Placing the Appliance To access the fixing holes on the fire table, the four components shown below need to be removed. The fire table should be bolted to the ground using at least 4 of the 10 fixing points on the bottom of the fire. -
Page 9: C4 Using The Weather Cover
C4 Using the Weather Cover Ensure that any fire is extinguished and the fire table is cool prior to fitting the weather cover. EP1350 Installation Manual 630504_0... -
Page 10: Burning Guide
Burning Guide Fuel Selection Only use dry firewood (less than 20% moisture content) or charcoal in the fire. D2 Starting the Fire If the fire is to be started for cooking, please proceed to section E. To start the fire, stack kindling (less than 30mm cross section) around the pyramid, allowing sufficient airflow between pieces. -
Page 11: Cooking Guide
To heat the grill, place it over the burning charcoal. To maintain heat, occasionally lift the cooking grill to add more charcoal as required. The metal plate surrounding the cooking grill can also be used for cooking (shaded grey below). Cooking Area of Fire Table EP1350 Installation Manual 630504_0... -
Page 12: E4 Using The Kebab Holder
Place damp wood chips (i.e. cedar, hickory, etc.) directly into the fire to provide a smoky flavour to the cooking food. Once you have finished cooking, remove the cooking tray prior to using the fire for standard outdoor heating. Using the Kebab Holder The fire table has been supplied with a set of kebabs and a kebab holder accessory for cooking. -
Page 13: F Maintenance
Excessive rubbing may mark the powder coated surface. Data Plate Location The serial number is located on the data plate, shown in the diagram below. To access the data plate, lift the two cooking grills. Data Plate Location EP1350 Installation Manual 630504_0... -
Page 14: General Warranty Terms And Conditions
Escea dealer. Nature of Warranty Subject to the exclusions in section 2 & 3, Escea may undertake to put right any defects in the Escea Outdoor Wood Fire products supplied by Escea for the periods specified below:... - Page 15 Where you make a claim under this warranty, an authorised repairer may need to attend your premises to inspect the Escea product. Escea may charge you a service call fee if a repairer will be required to travel more than 30 km from the nearest service centre to your location. You can obtain details on the location of service centres and service call fees by visiting the Escea website or calling the customer care line below.
- Page 16 Provide the Escea product serial number. • Provide reasonable proof of purchase for the Escea product. • If required, provide access to the premises at which the Escea product is located (so it can be inspected). Regions Escea Distributors Filing a Claim Australia Escea Australia PTY Ltd.
- Page 17 EP1350 Installation Manual 630504_0...
