Page 1: User Manual
BUILDING PROJECTOR BP-40 QW S DXX User Manual Please read the instructions carefully before use Innovation, Quality, Performance... - Page 2 CONTENT 1. Safety Instructions ................2 2. Technical Specifications ..............3 3. How To Set The Fixture ..............5 4. How To Control The Unit ............... 13 5. DMX512 Connections ..............15 6. Troubleshooting ................17 7. Cleaning And Maintenance ............18...
- Page 3 1. Safety Instructions Please read the instructions carefully which includes WARNING Please keep this User Guide for future consultation. If you sell the fixture to another user, be sure that they also receive this instruction booklet. Cautions： All fixtures are intact from the manufacturer, please operate follow up the user manual, artificial fault are not under guarantee repair.
- Page 4 Please look over power wires carefully, replace immediately if there is any damage. Please avoid any inflammable liquids, water or metal objects entering the fixture. Once it happens, cut off the mains power immediately. DO NOT operate in dirty and dusty environment, also cleaning fixtures regularly. ...
- Page 5 environment is getting dark; A nice design to put diffusion filter for changing beam angles; LED touch-panel display for easy set-up navigation; It also comes with great built-in shows (fade) without DMX control; Declaration of Conformity Perfect for illumination of building façade, hotels, landscapes, theme park and more.
- Page 6 3. How To Set The Fixture 7. Cleaning And Maintenance 3.1 Control Panel The cleaning must be carried out periodically to optimize light output. Cleaning frequency depends on the environment in which the fixture operates: moist, smoky or particularly dirty surrounding can cause greater accumulation of dirt on the fixture.
- Page 7 6. Troubleshooting 3. DMX IN: If the fixture does not work, no light, please check the connection of power cable Water proof 3-pin XLR connectors for DMX 512 operation and signal line, also measure the mains voltage on the main connector. 4.
- Page 8 circuit, when one of the units’ power is disconnected. DMX Address 4. Each lighting unit needs to have an address set to receive the data sent by the Channel Mode controller. The address number is between 0-511 (usually 0 & 1 are equal to 1). 5.
- Page 9 5. DMX512 Connections DMX 512 Address Select the , press the ENTER button and the display will blink. Use the DOWN and UP button to change the DMX 512 address between 1 and 512. Once the address has been selected, press the ENTER button to save or automatically exit menu mode without any change after one minute.
- Page 10 4.2 DMX 512 Configuration store or automatically return to the main functions without any change after one minute. To go back to the previous functions without any change press the MENU 4/5/7 Channels Mode: button. Blackout Mode Select the , press the ENTER button and the display will blink. Use the DOWN and UP button to select the (blackout) or (normal).
- Page 11 4. How To Control The Unit UP button to select the (red), (green), (blue), (yellow), (purple), (Cyan), (white) or (fade). You can operate the unit by DMX controller: Once select , press the ENTER button to setup. press the ENTER button， No need to turn the unit off when you change the DMX address, as new DMX will blinking on the display, use DOWN and UP button adjust the fade time address setting will be affected at once.
- Page 12 LED Display Photo Cell Intensity Select the , press the ENTER button and the display will blink. Use the DOWN and UP Select the , press the ENTER button and the display will blink. Use the button to adjust the intensity value between .
