- Page 1 SMART CONNECTION TO SMART HOME VENTO Expert A50-1 W VENTO Expert Duo A30-1 W OPERATION MANUAL...
- Page 2 VENTO Expert www.blaubergventilatoren.de CONTENTS Purpose ....................2 Network parameters ................3 Control commands ................3 Feedback ....................4 PURPOSE A smart home is controlled only by the designated master device. All other devices such as telephones and the smart home system are slaved to the master one via WiFi. The master automatically transmits control signals to the slaves. A wireless network can be arranged in two ways: A master device with its integrated Wi-Fi access point with a maximum of four slave devices connected.
-
Page 3: Network Parameters
• Other IP – the master device connects to the router WiFi access point (Connection diagram 2). The master device IP address is set manually by launching the Blauberg Vento.exe file on your PC. The master device port is 4000. - Page 4 VENTO Expert www.blaubergventilatoren.de FEEDBACK 7... 0x6D 0x61 0x73 0x74 0x65 0x72 Parameter1 value1 … Parameter n value n Parameters, Size, Description Value, dec [bytes] 0 – Off Device status (On/Off) 1 – On 1 – Low 2 – Medium Selected speed 3 –...
- Page 5 VENTO Expert www.blaubergventilatoren.de There are four types of feedback packets: 1. Control page data. Parameters: 3,9,12,19,13,26,4,5,6,8,14,18,20,37 2. Settings page data. Parameters: 11,21,22,23,15,16,17,25,31 3. Slave device search data: Parameters: 27 4. Response to «Slave device search» request. Parameters: 28 Feedback packet 1 is sent in response to control commands 1,3,4,5,6,9 and 30. Feedback packet 2 is sent in response to control commands 2,21,22,23 and 31.
- Page 6 www.blaubergventilatoren.de VENTO_Expert(DUO)_W_SmartHouse_v.1(1)_EN...
