- Page 1 AxiAl pressurisAtion fAn Axis-P USER’S MANUAL...
-
Page 2: Table Of Contents
Warranty card ....................................19 This user’s manual is a main operating document intended for technical, maintenance, and operating staff. The manual contains information about purpose, technical details, operating principle, design, and installation of the Axis-P unit and all its modifications. -
Page 3: Safety Requirements
Axis-p www.blaubergventilatoren.de SAFETY REQUIREMENTS All operations described in this manual must be performed by qualified personnel only, properly trained and qualified to install, make electrical connections and maintain ventilation units. Do not attempt to install the product, connect it to the mains, or perform maintenance yourself. -
Page 4: Purpose
PURPOSE The axial pressurisation fan of Axis-P series is used for ventilation of industrial, administrative, residential and other buildings. It is also used for pressurisation of fire-fighting equipment and fresh air supply in case of fire. The fan is intended for general ventilation in systems with high air flow rates. -
Page 5: Designation Key
DESIGNATION KEY Casing Motor Impeller Modification AxIS-P 6 3 0 K-2 D / 5.5- 8 / 3 5 / A L - U 1 - K Axis-P: axial pressurisation fan Standard size (air duct size) [mm] Casing modification: _: standard casing... -
Page 6: Technical Data
Axis-p www.blaubergventilatoren.de TECHNICAL DATA • Transported air temperature depends on the applied climatic category (see the designation key). • The maximum permissible concentration of solids and dust in the handled air is 10 mg/m3. • The unit is rated as a Class I electrical appliance. -
Page 7: Unit Design And Operating Principle
Axis-p www.blaubergventilatoren.de UNIT DESIGN AND OPERATING PRINCIPLE Fan with a casing modi cation without terminal box Fan with a casing modi cation with a terminal box Impeller Impeller Access door Access door Inlet ring VK-AF * Inlet ring VK-AF *... -
Page 8: Mounting And Set-Up
Axis-p www.blaubergventilatoren.de MOUNTING AND SET-UP ALL OPERATIONS DESCRIBED IN THIS USER’S MANUAL MUST BE PERFORMED BY QUALIFIED PERSONNEL ONLY, PROPERLY TRAINED AND QUALIFIED TO INSTALL AND MAINTAIN VENTILATION EQUIPMENT. DO NOT ATTEMPT TO INSTALL THE PRODUCT YOURSELF. IT IS UNSAFE AND IMPOSSIBLE WITHOUT SPECIAL KNOWLEDGE. - Page 9 Axis-p www.blaubergventilatoren.de Mounting in case of no ductwork upstream of the fan Obstructed space installation If the ductwork is not available at the fan inlet, the inlet cone VK-AF must To ensure normal operation of the fan in an obstructed space make sure be installed to improve aerodynamic parameters of the air flow.
-
Page 10: Connection To Power Mains
Axis-p www.blaubergventilatoren.de CONNECTION TO POWER MAINS DISCONNECT THE POWER SUPPLY PRIOR TO ANY OPERATIONS WITH THE UNIT. CONNECTION OF THE UNIT TO POWER MAINS IS ALLOWED BY A QUALIFIED ELECTRICIAN WITH A WORK PERMIT FOR THE ELECTRIC UNITS UP TO 1000 V AFTER CAREFUL READING OF THE PRESENT USER’S MANUAL. - Page 11 Axis-p www.blaubergventilatoren.de ASYNCHRONOUS ELECTRIC MOTOR STARTING METHODS There are several methods for starting asynchronous squirrel-cage electric motors. The most common methods are: direct-on-line (DOL), with a soft starter (SS) or with a frequency converter (FC). Direct-on-line starting In case of direct-on-line starting (i.e. by connecting the motor to the electric mains with a simple line contactor), the motor starting time significantly increases due to high inertia of the impeller, which, in turn, results in high in-rush starting currents in the circuit.
-
Page 12: Commissioning
Axis-p www.blaubergventilatoren.de Problems associated with DOL starting The problems caused by DOL starting may be divided into two groups: An abrupt start causes mechanical shock, jolts in the mechanism, shock removal of free play etc. A heavy start cannot be completed. -
Page 13: Technical Maintenance
Axis-p www.blaubergventilatoren.de TECHNICAL MAINTENANCE DISCONNECT THE UNIT FROM POWER SUPPLY BEFORE ANY MAINTENANCE OPERATIONS! MAKE SURE THE UNIT IS DISCONNECTED FROM POWER MAINS BEFORE REMOVING THE PROTECTION PRIOR TO COMMENCING ANY TECHNICAL MAINTENANCE PUT UP A PROHIBITORY SIGN ON THE FAN STARTING PANEL: “DO NOT SWITCH ON! MEN AT WORK!”... - Page 14 Axis-p www.blaubergventilatoren.de The fan fails to reach the Fan motor overloaded. Eliminate the overload. required rotation speed due to Improper fan starting method. Use a soft starter or frequency converter to start the motor serious overheating of the fan (see “Asynchronous Electric Motor Starting Methods”...
-
Page 15: Storage And Transportation Regulations
Axis-p www.blaubergventilatoren.de STORAGE AND TRANSPORTATION REGULATIONS • Store the unit in the manufacturer’s original packaging box in a dry closed ventilated premise with temperature range from +5 °C to + 40 °C and relative humidity up to 70 %. •... -
Page 16: Manufacturer's Warranty
Axis-p www.blaubergventilatoren.de MANUFACTURER’S WARRANTY The product is in compliance with EU norms and standards on low voltage guidelines and electromagnetic compatibility. We hereby declare that the product complies with the provisions of Electromagnetic Council Directive 2014/30/EU, Low Voltage Directive 2014/35/ EU and CE-marking Directive 93/68/EEC. - Page 17 Axis-p www.blaubergventilatoren.de...
- Page 18 Axis-p www.blaubergventilatoren.de...
-
Page 19: Certificate Of Acceptance
Axis-p www.blaubergventilatoren.de CERTIFICATE OF ACCEPTANCE Unit Type Axial pressurisation fan Model Serial Number Manufacture Date Quality Inspector’s Stamp SELLER INFORMATION Seller Address Phone Number E-mail Purchase Date This is to certify acceptance of the complete unit delivery with the user’s manual. The warranty terms are acknowledged and accepted. - Page 20 www.blaubergventilatoren.de B118EN-05...
