SDB680 – INSTALLATION GUIDE
C
6.3 ONFIGURING THE
6.3.1 Changing the Platform and Application Software
9.
On the PC, open an internet browser and access the Simoco webpage.
10. On the Simoco webpage, select 'Partner Login' and login to the Partner Portal area.
11. When logged in to the Partner Portal, navigate to the 'Resource Library' > 'Software Downloads' >
'DMR' > 'Simoco Xd Infrastructure' page and ensure that you have the latest version of the 'DMR
Tier II' > 'DMR Base' software. If necessary, download the latest software to the PC.
Note.
The versions of DMR Base software listed and available on the Partner Portal contain two software
files. These are the Cerebral Platform software and the Application software. The files are in the
form CerebralPlatform_R.X.X.X.tar.gz and DMRT2_RX.X.X.tar.gz, where RX.X.X refers to the
version of software released in each case.
12.
On the PC, start and login to the SDMT.
13.
On the SDMT main screen, carry out the following:
13.1. On the ribbon bar, select the 'DMR Tier II' tab.
13.2. On the Site View tab of the Navigation Pane, from the navigation tree, click on the 'System'
branch to expand it. Click on the 'Site 1' node displayed.
13.3. On the Ribbon bar, select the 'Add Digital Base' button to add a digital base to Site 1 on the
navigation tree.
13.4. On the Site View tab of the Navigation Pane, from the navigation tree, select the new DMR
Base that has just been added to the navigation tree. The Base configuration page will be
displayed in the configuration page area.
13.5. On the base Configuration page on the Base Settings tab, set the 'IP Address' to that of the
new Tier II base station noted in Para 1 or that sent to the base with the IP Configuration tool
as appropriate.
13.6. On the tab of the base configuration page, select the
changes that have been made to the configuration page.
13.7. On the DMR Tier II ribbon bar, select the 'Software Upload' button. The 'Upload to Base(s)'
page will be displayed.
13.7.1. On the Upload to Base(s) page, select the 'Browse' button for the Application
Software File. An Open file dialogue window will be displayed.
14.
On the 'Open' file window, navigate to and select the latest version of the DMR Tier II Application
Software downloaded at Para 11. Select the Open button to load the file into the SDMT.
15. On the SDMT main screen, on the Upload to Base(s) page, select the 'Browse' button for the Cerebral
Platform File. An Open file dialogue window will be displayed.
16.
On the 'Open' file window, navigate to and select the latest version of the DMR Tier II Cerebral
Platform software downloaded at Para 11. Select the Open button to load the file into the SDMT.
17. On the SDMT main screen, carry out the following:
May 15
DMR B
ASE
Page 42
icon that is displayed to save the
CONFIGURATION TIER III – TIER II
TNM-I-E-0046
