SDB680 – INSTALLATION GUIDE
5.1. Install the SDMT software in accordance with Section 1.2 – Software Installation.
5.2. Prepare the SDMT software for use in accordance with Section 2.2 – SDMT Preparation.
5.3. Create or establish a connection to a suitable Microsoft SQL Server database in accordance
with Section 2.2.3 – Database Connection.
I
4.4
NSTALLING THE
6.
Refer to the Simoco IP Configuration Tool User Manual [3] and install the Simoco IP Configuration
Server software in accordance with Section 1.3 – Software Installation.
7. After installing the Simoco IP Configuration Tool software, ensure that the PC on which the software
is installed is connected to the Ethernet switch via a CAT 5 Ethernet cable.
IP A C
4.5
DDRESS
8.
On the PC, start the Simoco IP Configuration Tool.
9.
If the PC has more than one IP address or Network Connection, when the IP Configuration Tool is
started, the Interface Selection screen will be displayed (see Figure 12 below).
10.
On the Interface Selection screen, select the relevant IP address that is to be used for communicating
with the base station(s).
11. Once the IP address has been selected the Simoco IP Configuration Tool main screen will be displayed
(see Figure 13 below).
May 15
S IP C
IMOCO ONFIGURATION
ONFIGURATION

Figure 12. Interface Selection screen.

Figure 13. IP Configuration Tool main screen

Page 32
TNM-I-E-0046
S
ERVER
CONFIGURATION TIER III BASE
