SDB680 – INSTALLATION GUIDE
P4 USB B
The Universal Serial Bus (USB) Type B connector is used as the peripheral connection. The connector pin-
outs are detailed below in Table 4.
Table 4. USB Type B Connector Pin-outs.
Pin
Function
1
Vcc (+5 V)
2
Data -
3
Data +
4
Ground
P5 Ethernet
The P5 Ethernet connector uses standard network cable wiring for an RJ45, which is detailed below in Table
5.
Table 5. Ethernet RJ45 Connector Pin-outs.
Pin
Description
1
Tx Data+, balanced I/P 1
2
Tx Data-, balanced I/P 2
3
Rx Data+, balanced O/P 1
4
NC
5
NC
6
Rx Data-, balanced O/P 2
7
NC
8
NC
S2 Serial Port
The connector pin-outs for the 9-way D Type S2 Serial Port are shown below in Table 6.
Table 6. S2 Serial Port Connector Pin-outs.
Pin
Function
1
Connected to pin 4 and 6
2
Tx 1
3
Rx 1
4
Connected to pin 1 and 6
5
0 V
6
Connected to pin 1 and 4
7
Rx 2 (opt CTS 1)
8
Tx 2 (opt RTS 1)
9
NC
