SDB680 – INSTALLATION GUIDE
12. Refer to the Simoco IP Configuration Tool User Manual [3] and configure the IP Address for the
relevant MAC Address listed in the data grid of the main screen in accordance with Section 2.2 –
Configuring an IP Address.
C
4.6
ONFIGURING THE
4.6.1 Platform and Application Software Update
13. On the PC, open an internet browser and access the Simoco webpage.
14. On the Simoco webpage, select 'Partner Login' and login to the Partner Portal area.
15. When logged in to the Partner Portal, navigate to the 'Resource Library' > 'Software Downloads' >
'DMR' > 'Simoco Xd Infrastructure' page and ensure that you have the latest version of the 'DMR
Tier III' > 'DMR Base' software. If necessary, download the latest software to the PC.
Note.
The versions of DMR Base software listed and available on the Partner Portal contain two software
files. These are the Cerebral Platform software and the Application software. The files are in the
form CerebralPlatform_R.X.X.X.tar.gz and DMRT3_RX.X.X.tar.gz, where RX.X.X refers to the
version of software released in each case.
16.
On the PC, start and login to the SDMT. The System Selector screen will be displayed.
17.
On the 'System Selector' screen, carry out either of the following:
17.1. If the base station is to be added to an existing Tier III system, select the system number from
the displayed list and select the 'OK' button.
17.2. If the base station is to be added to a new Tier III system, enter the system number for the new
system and select the 'OK' button.
Note.
The Tier III system number selected or entered above must match that entered when configuring
the IP address for the Tier III base station. Refer to Para 12 above and Para 2.3 of Section 2.2 –
Configuring an IP Address in the Simoco IP Configuration Tool User Manual [3] for clarification.
18.
On the SDMT main screen, carry out the following:
18.1. On the ribbon bar, select the DMR Tier III tab.
18.2. On the DMR Tier III ribbon bar, select the System Commands button. The System I/O page
will be displayed.
18.3. On the System I/O page, select the 'Browse' button for relevant software you wish to upload
(i.e. Cerebral Platform or Application Software). An open file dialogue window will be
displayed.
19.
On the 'Open' file window, navigate to and select the latest version of DMR Tier III software (i.e.
Cerebral Platform or Application Software) downloaded at Para 15. Select the Open button to load
the file into the SDMT.
20.
Repeat Para 18.3 and Para 19 for the other type of software (i.e. Cerebral Platform or Application
Software) as required.
21. On the SDMT, on the System I/O Page, carry out the following:
