SDB680 – INSTALLATION GUIDE
14. On the 'Open' file window, navigate to and select the latest version of the DMR Tier III Application
Software downloaded at Para 10. Select the Open button to load the file into the SDMT.
15.
On the SDMT main screen, on the Upload to Base(s) page, select the 'Browse' button for the Cerebral
Platform File. An Open file dialogue window will be displayed.
16. On the 'Open' file window, navigate to and select the latest version of the DMR Tier III Cerebral
Platform software downloaded at Para 10. Select the Open button to load the file into the SDMT.
17.
On the SDMT main screen, carry out the following:
17.1. On the Upload to Base(s) page, carry out the following:
17.1.1. Select the base(s) you wish to upload the software to.
17.1.2. Select the 'Upload' button to programme the base with the Application Software and
the Cerebral Platform.
17.2. On the DMR Tier II ribbon bar, select the Re-boot button. The Re-boot Base(s) page will be
displayed.
17.3. On the Re-boot Base(s) page, select the base station(s) that the software was uploaded to and
select the 'Re-boot' button. The base station(s) will re-boot and load the new versions of
software.
5.4.2 Tier III IP Address Configuration
18. On the IP Configuration Tool, in the data grid of the main screen, select the relevant MAC Address for
the Tier II Base.
19.
Refer to the Simoco IP Configuration Tool User Manual [3] and configure a Tier III IP Address for
the relevant MAC Address listed in the data grid of the main screen in accordance with Section 2.2 –
Configuring an IP Address. Ensure that the 'System', 'VAC', 'Site' and 'Base' details entered are
relevant to the Tier III system.
Note.
When configuring the IP address for the Tier III base station, the Tier III 'System' number entered
above must match the system number that the Tier III base station is to be added to. Refer to Para
12 above and Para 2.3 of Section 2.2 – Configuring an IP Address in the Simoco IP Configuration
Tool User Manual [3] for clarification.
5.4.3 Software Licence Update
20.
On the SDMT main screen, on the ribbon bar, select the DMR Tier III tab.
20.1. On the DMR Tier III ribbon bar, select the System Commands button. The System I/O
configuration page will be displayed.
20.2. On the System I/O page, in the System Monitor area, expand the navigation tree and check
that the new Tier III base has been added to the system.
20.3. On the System I/O page, select the 'Browse' button for the Licence file. An Open file
dialogue window will be displayed.
21. On the 'Open' file window, navigate to and select the relevant software licence file. Select the Open
button to load the file into the SDMT.
22.
On the SDMT main screen, on the System I/O page, carry out the following:
