SDB680 – INSTALLATION GUIDE
RECOMMENDED TOOLS AND TEST EQUIPMENT
The following list of Tools, Electrical Engineering Test Equipment and Materials are required to carry out
the Assembly procedures contained in this document.
T
OOLS
1. Electric Drill (preferably with Hammer Action).
2. 7.5 mm Drill Bit.
3. Spirit Level.
4. Pozidriv Screwdriver.
T E
EST QUIPMENT
5. Anritsu/Wiltron S331A Test Set.
6. Earth Bonding Test Set.
7. Dummy Load.
Wattmeter (50
8.
C
ABLES
9. USB Cable.
10. Ethernet Switch Cable.
M
ATERIALS
11. 4 x M4 x 12 Screws (supplied).
12. 4 x Rawlplugs (supplied).
13. 4 x No. 12 x 1½" Woodscrews (supplied).
14. M6 x 12 mm Pan Head Pozidriv Retaining Bolts.
15. M6 x 16 mm Pan Head Pozidriv Retaining Bolts.
16. M6 Nuts and Plain Washers.
17. Plastic Cup Washers.
18. M6 Cage Nuts.
O I
THER TEMS
19. Personal Computer (PC) with the following Software Applications installed:
(a).
Simoco Digital Management Terminal (SDMT).
(b). Simoco IP Configuration Tool.
