SDB680 – INSTALLATION GUIDE

RACK MOUNT INSTALLATION PROCEDURE

2
The SDB680 Base Station is designed to be fitted in a standard 403 mm (19") rack. This procedure
should be followed when installing all new SDB680s into a 19" racking system.
T , T E
OOLS EST QUIPMENT AND
The following Tools, Test Equipment and Materials will be required to perform this procedure:
Pozidriv Screwdriver
4 x M6 x 12 mm Pozidriv Retaining Bolts
4 x M6 x 16 mm Pozidriv Retaining Bolts
8 x M6 Nuts and Plain Washers
M6 Cage Nuts
Anritsu/Wiltron S331A Test Set
Earth Bonding Test Set
R P
2.1
ACK REPARATION
Note.
Rack runner fittings differ between the various rack manufacturers. If the procedure described
below does not apply to the type of rack being used, the procedure should be modified to suit.
1. Ensure that the rack chosen for installation is firmly bolted together and is securely anchored to the
floor or wall to prevent overbalancing.
2. In the rack, plan out the locations of equipment before commencing installation.
Notes:
(i).
Each SDB680 requires 2U height of rack space.
(ii).
Unused space should be blanked off to prevent uncontrolled circulation of air.
(iii).
If used, the associated PSU TRAY requires either 1U or 2U height of rack space and is designed to
locate adjacent to the base station.
(iv).
When the SDB680 is installed into a rack, support shelves or side slide runners should be used.
These are available from Simoco and supplied as a pair with all the necessary screws for securing
them.
EQUIPMENT DAMAGE. When the SDB680 Base Station is installed into a rack, DO
NOT use the front panel attachment points to support the full weight of the equipment
or damage to the equipment may result. Suitable shelves or supports MUST be
provided to support the body of the base station along the length of each side.
3. Unpack all the equipment and retain the packaging.
May 15
M R
ATERIALS EQUIRED
CAUTION
Page 24
TNM-I-E-0046
RACK MOUNT INSTALLATION
