SDB680 – INSTALLATION GUIDE
22.1. In the System Monitor area, on the navigation tree, right click on the VAC for the system.
Menu options will be displayed.
22.2. From the VAC menu options, select 'Update' > 'Update Software'.
22.3. In the Comms History area, confirm that a 'Starting Update Software' message is displayed.
22.4. The progress of the update operation will be displayed in the 'Current Message Progress' area.
22.5. In the Comms History area, after a short delay, confirm that a 'Completed Update Software'
message is displayed.
22.6. In the System Monitor area, on the navigation tree, right click on the VAC for the system.
Menu options will be displayed.
22.7. From the VAC menu options, select 'Base Operations' > 'Reboot Base(s)'. The Reboot
Base(s) warning message will be displayed.
22.8. On the Reboot Base(s) warning message, select 'Yes' to continue.
22.9. In the Comms History area, after a short delay, confirm that a 'Resetting VAC' message is
displayed.
22.10. In the Comms History area, various messages for the reboot operation will be displayed.
Eventually, as the reboot of each base station in the Tier III system is completed, an
appropriate 'Discovered Base' message will be displayed.
5.4.4 Configuration Creation and Upload
23. On the SDMT main screen, carry out the following:
23.1. Refer to Part 3 of the SDMT User Manual [2] and create a working configuration that includes
the new DMR Base and appropriate for the system in which it is installed.
23.2. When creating a working configuration, ensure that any changes to the configuration are saved
by selecting the
pages. This will save the changes to the local SQL Server ® database stored on the PC.
23.3. On the ribbon bar, select the System Commands button. The System I/O configuration page
will be displayed.
23.4. On the System I/O page, carry out the following:
23.4.1. In the 'Select Read/Write System Areas' box, depending on the configuration you
wish to write, select either the 'Configuration', the 'Subscribers' or both. Select the
'Write to System' button.
23.4.2. In the Comms History area, confirm that a 'Starting Write All Config' message is
displayed.
23.4.3. The progress of the write operation will be displayed in the 'Current Message
Progress' area.
23.4.4. In the Comms History area, after a short delay, confirm that a 'Completed Write All
Config' message is displayed.
23.4.5. When the write operation is completed, the success or failure of the operation for each
VAC, Site or Base will be indicated in the Comms History area.
May 15
icon that will be displayed on the page tab of the relevant configuration
Page 39
CONFIGURATION TIER II – TIER III
TNM-I-E-0046
