- Page 1 Tension meter dynarope HF36/1/LPT Operation and maintenance manual...
-
Page 2: Table Of Contents
SUMMARY 1. DEFINITIONS ........................3 2. PICTOGRAMS USED IN THIS MANUAL ................3 3. STANDARD CONTENT OF DELIVERY ................3 4. INTRODUCTION ........................4 4.1. Description ................................. 4 4.2. Characteristics ..............................4 4.3. Data bank HF 36/1/LPT ..........................4 4.4. Specific calibration ............................ - Page 3 9. Tractel® declines any responsibility for use of this unit in a setup configuration not described in this manual.
-
Page 4: Definitions
1. DEFINITIONS In this manual, the following terms mean: « Product » : Equipment element or assembly defined on the cover page, delivered complete in its standard version, or as one of the various models described. « Installation » : Comprehensive set of operations required to place a complete product in a condition ready for commissioning (or connection to other components for commissioning), starting from the state in which the product has been delivered. -
Page 5: Introduction
4. INTRODUCTION 4.1. Description This tension meter dynarope HF 36/1 LPT is an electronic load cell that has been designed to measure the effort applied in a wire rope without having to dismantle the installation. The resulting signal generated by the sensor equipped with strain gauges is interpreted by a digital display controlled by a microprocessor. -
Page 6: Specific Calibration
Ref. Nominal Nominal Nominal Range Item Material Structure Calibration diameter (mm) diameter (/'') diameter (mil'') (daN) 3032 Inox 19 x 1 3/16 0,1969 60 - 600 3033 Inox 19 x 1 0,2362 70 - 900 3007 Inox 19 x 1 0,2756 100 - 1200 3034... -
Page 7: Presentation
5. PRESENTATION 5.1. Tension meter HF 36/1/LPT Crank Sheaves Bronze nut Support of the sheave Tightening Screw Strain gages Crank support LEMO Plug Stop block Axle of the sheave LEMO cable LEMO connector is a « push-pull » connector. The LEMO self-latching system allows the connector to be mated or unmated by simply pushing or pulling axially on the outer release sleeve. -
Page 8: Display Hf 87/T/Lpt
5.2. Display HF 87/T/LPT Display Batteries cover fixing screws Key board Batteries AA 1,5V USB Plug (option) Gasket LEMO plug Batteries cover LEMO connector is a « push-pull » connector. The LEMO self-latching system allows the connector to be mated or unmated by simply pushing or pulling axially on the outer release sleeve. -
Page 9: Display Information And Keyboard Functions
5.3. Display information and keyboard functions A Battery level indication B Current temperature C GPS Status D Current unit Information about the type of tension F Current measure meter T Key • Press 3 sec = increase police of the current measure Graphic visualization of the measure between •... -
Page 10: To Carry A Measurement Out
• Connect the tension meter to the display using the provided LEMO cable. • Turn the display "ON", the screen will display : ® o Tractel logo o Parameters setting values • Select the type of tension meter presently connected to your display. (e.g.: 36 /3 ) -
Page 11: To Install The Tension Meter On The Wire Rope
6.1. To install the tension meter on the wire rope • Use the crank in order to unscrew the tightening screw • Place the two sheaves onto the wire rope • Use the crank to tight the tightening screw until the wire rope gets in firm contact with the stop block Once the cable is in contact with the rotary stop block, confirm with a ¼... -
Page 12: Configuration Menu
7. CONFIGURATION MENU • Accede to the Menu by pressing the • Use the key board to scroll the menu (See § 5.3 ) ON/OFF PARAMETRES LANGUAGE AUTO OFF BACKLIGHT TIME DATE INFORMATION RESTORE RECORDS READ DELETE UNITS LOAD DIAMETER TEMPERATURE •... -
Page 13: Advanced Functions
• RECORDS READ Read the recorded values DELETE To clear the memory • UNITS LOAD UNITS N, daN, kN, kg, lbf, lbs "g" COEFFICIENT Modify the default parameter : 9,81 DIAMETER Available units: mm, decimal inches, fraction inches. TEMPARATURE Available units : C° and F° 8. -
Page 14: Record
• Repeat the operation with up to 5 measurements. If you try to add a 6 measurement, the error message “!” will appear. • Press F1 during 2 seconds to leave the average mode 8.2. Record To record the data at the end of a measurement process •... -
Page 15: Use
8.3.2 Use • Press F2 and select the cable -- Special -- (first line of the list) • Select an existing custom calibration o Select “Use” with key to use the custom calibration • The display shows the current effort with, at the bottom left of the screen, the reference of the selected custom calibration and the value of the calibration The effort will only be accurate at this calibration value. -
Page 16: Maintenance
International Standard calibrator. ® Tractel recommends an annual metrological check for every appliance. 9.3. Maintenance The sensor/display unit requires no specific maintenance other than a regular cleaning with a dry cloth. -
Page 17: Error Messages
10.2. Error messages Message Cause Solution Use the optional « LOADER » software to update Corrupted Error in the wire rope parameters. the data bank. signature Or, consult the manufacturer. Use the optional « LOADER » software to update Corrupted Error in the wire rope parameters. -
Page 18: Product Markings
PRODUCT MARKINGS HF 36/1/LPT n° : XXXXXX Ø : 5 to 13 mm (3/16 to 1/2 in) 5.000 daN (11200 lbs) Made in Belgium : IP 65 HF 87/T/LPT n° : XXXXXX : IP 65 Made in Belgium : AA (1.5 VDC) x 3 Serial number Identification (TYPE) Wire rope diameters range...
