USER MANUAL
Table of Contents
Safety Information..............................................................3
Specifications.................................................................... 4
Main Power Connection.......................................................5
Signal Connection...............................................................5
Main Control Menu......................................................................... 6
DMX Profile.................................................................................... 8
Wireless DMX Set Up.........................................................10
Rigging the Fixture..............................................................11
Cleaning & Maintenance.................................................................11
Parts List.........................................................................................11
Advertisement
Table of Contents
Related Manuals for Mega Lite Piccolo Blinder 120
Summary of Contents for Mega Lite Piccolo Blinder 120
-
Page 1: Table Of Contents
USER MANUAL Table of Contents Safety Information…………………………………………………..…3 Specifications………………………………………………………….. 4 Main Power Connection……………………………………………….5 Signal Connection………….…………………………………………..5 Main Control Menu................. 6 DMX Profile..................8 Wireless DMX Set Up…………………………………………………10 Rigging the Fixture……………………………...……………………..11 Cleaning & Maintenance..............11 Parts List..................11... - Page 3 Check that the unit has not been damaged during transport Check that the unit has not been damaged during transport Protection Against Fire Protection Against Fire 1. Maintain a minimum of 1 foot distance from any type of flame. 1. Maintain a minimum of 1 foot distance from any type of flame. 3.
-
Page 4: Specifications
Technical Information Part Numbers 1305-Piccolo Blinder Mechanical Specifications Power Connection: Screw Type with Nema 5/15 adapter 7.25” 4.25” IP Rating: IP 65 DMX Connection: Seetronics IP 65 XLR 3 pin in / out Power Connection: Lindya Ip68 UL Screw type connection to Edison Fastening System: Quick Release clamp mount Thermal:... -
Page 5: Main Power Connection
Main Power Connection Caution! Do not connect fixture to a dimmer system. This unit has Auto switching power supply. It will respond to 110V or 220V automatically This unit must be earthed. (electronically grounded) Replace fuse only with the specified type and rating. This fixture has power in and out via Lindya Ip68 UL listed screw type power connections rated at 13Amps. -
Page 6: Control Board
The control board on the fixture is your interface to access and control all the functions on the unit. Its digital display gives you a code view of Mega Lite the options and functions. The following will explain each function and Piccolo 120 its options. -
Page 7: Main Control Menu
Config menu Config Mode / Dimmer Setting Keep Screen On Keep DMX Data Press Enter to establish your Default Dimmer settings. Use the up/down keys to >Dimmer Setting Select dimmer type setting. Press Enter to confirm the setting. Press ESC to return to Main Menu. -
Page 8: Dmx Profile
DMX Profile Piccolo 120 1CH Mode DMX Chanel Function Description Value Init Dimmer Warm White LED intensity 0-255 Piccolo 120 2CH Mode DMX Chanel Function Description Value Init Dimmer Dimmer 0-255 No Function Strobe (slow to fast) 5-196 Strobe Random Strobe (slow to fast) 197-255 Piccolo 120 5CH Mode DMX Chanel... -
Page 9: Rigging The Fixture
Rigging the fixture Caution! 1. The installations must be carried out by an authorized dealer or trained professional. 2. Unit may cause severe injures if you have doubts concerning the safety do not install. 3. Unit is to be 24inches away from flammable materials (decoration material) 4. -
Page 10: Warranty Information
Customer Support Mega Lite has a customer support line to provide set up help and to answer any question should you encounter a prob- lem. Please visit our website for any other related technical documents. For service related issue please contact our service dept.
