USER MANUAL
Safety Information.............................................................................................3
Specifications...................................................................................................4
Main Power Connection.....................................................................................5
DMX-512 Connection.........................................................................................5
Main Control Menu..............................................................................................................6
DMX Profile.........................................................................................................................8
Rigging the Fixture............................................................................................9
Cleaning & Maintenance....................................................................................................10
Parts List............................................................................................................................10
Advertisement
Table of Contents
Related Manuals for Mega Lite NOVA-LITE Q200
Summary of Contents for Mega Lite NOVA-LITE Q200
-
Page 1: Table Of Contents
USER MANUAL Table of Contents Safety Information…………………………………………………………..…………………….3 Specifications……………………………………………………………………………………...4 Main Power Connection………………………………………………………………………….5 DMX-512 Connection…………………………………………………………………...………..5 Main Control Menu......................6 DMX Profile.........................8 Rigging the Fixture………………………………………………………………………………..9 Cleaning & Maintenance....................10 Parts List..........................10... -
Page 3: Table Of Contents Safety Information
Check that the unit has not been damaged during transport Protection Against Fire 1. Maintain a minimum of 1 foot distance from any type of flame. 3. Replace fuse only with the specified type and rating. 4. Do Not install the unit to close to a heat source. 5. -
Page 4: Specifications
Technical Information Part Numbers 4450-Nova-Lite Q200 Mechanical Specifications DMX Connectors: Neutrik 3 & 5 pin Power connection: Neutrik Power Con to Nema 5-15 (cable mounted) Thermal: Maximum ambient temperature 105° Maximum surface temperature 113° 10.25” Fastening System: Dual Yoke Display:... -
Page 5: Main Power Connection
Main Power Connection Caution! Do not connect fixture to a dimmer system. This unit has Auto switching power supply. It will respond to 110V or 240V automatically This unit must be earthed. (electronically grounded) The occupation of the connection-cable is as follows: This fixture is equipped with an electronic power supply that will let the unit operate from 100V to 240V from 50Hz to 60Hz Cable (USA) Cable (EU) -
Page 6: Main Control Menu
Display Menu CONTROL BOARD MegaLite NovaQ200 Mode Set Up Down Address DMX Address Press Set Up to select the DMX start channel use the up/down keys, Press Set Up to confirm the setting Channel Mode DMX Mode This function allows you to select the mode in witch you want to control the fixture. Press Set Up use the up/down keys to select desired DMX mode settings. - Page 7 Strobe Mode Strobe This function allows you to select a preprogrammed strobe sequences. Press Set Up use the up/down keys to select desired strobe program (15 options). Press Enter to set the desired sped use the up/down keys (15 options). Press Set Up to confirm the settings.
-
Page 8: Dmx Profile
DMX Profile Nova-Lite Q200 3CH Mode DMX Chanel Function Description Value LED Color Red LED intensity 0-255 LED Color Green LED Intensity 0-255 LED Color Blue LED Intensity 0-255 Nova-Lite Q200 4CH Mode DMX Chanel Function Description Value LED Color... -
Page 9: Rigging The Fixture
Nova-Lite Q200 8CH Mode DMX Chanel Function Description Value Dimmer Dimmer Off to Full 0-255 LED Color Red LED intensity 0-255 LED Color Green LED Intensity 0-255 LED Color Blue LED Intensity 0-255 LED Color White LED Intensity 0-255 No Function... -
Page 10: Cleaning & Maintenance
Pendant Mount: When using pendant and treaded mount consider the following 1) Remove the yoke as it will no longer be used. 2) Using a standard 1/2 bolt you can hang the fixture by thread- ing directly into the top. ( a metric 10mm version is also available part #4450-HPM) 3) Using a steel cable you can hang the fixture by running a steel cable throw the side hole... - Page 11 Warranty Information Warranty Conditions -Unless otherwise stated in writing, your product is covered by a one year parts and labor limited warranty. -LEDs are not guaranteed to match in color temperature or output. -It is the owner’s responsibility to furnish receipts or invoices for verification of purchase, date, and reseller or distributor. If purchase date cannot be provided, date of manufacture will be used to determine warranty period.
