USER MANUAL
Safety Information.............................................................................................3
Specifications...................................................................................................4
Main Power Connection.....................................................................................5
DMX-512 Connection.........................................................................................5
Main Control Menu..............................................................................................................6
DMX Profile.........................................................................................................................8
Rigging the Fixture............................................................................................8
Cleaning & Maintenance.....................................................................................................9
Parts List..............................................................................................................................9
Advertisement
Table of Contents
Related Manuals for Mega Lite NOVA-LITE WW150
Summary of Contents for Mega Lite NOVA-LITE WW150
-
Page 1: Table Of Contents
USER MANUAL Table of Contents Safety Information…………………………………………………………..…………………….3 Specifications……………………………………………………………………………………...4 Main Power Connection………………………………………………………………………….5 DMX-512 Connection…………………………………………………………………...………..5 Main Control Menu......................6 DMX Profile.........................8 Rigging the Fixture………………………………………………………………………………..8 Cleaning & Maintenance.....................9 Parts List..........................9... -
Page 3: Table Of Contents Safety Information
Check that the unit has not been damaged during transport. Report any shipping damages to the shipping company. Protection Against Fire 1. Maintain a minimum of 1 foot distance from any type of flame. 3. Replace fuse only with the specified type and rating. 4. -
Page 4: Specifications
Technical Information Part Numbers 4452– Nova Lite WW150 Mechanical Specifications DMX Connectors: Neutrik 3 & 5 pin Power connection: Neutrik Power Con to Nema 5-15 (cable mounted) Thermal: Maximum ambient temperature 105° Maximum surface temperature 113° 10.25” Fastening System: Dual Yoke Display: Digital Lens Angle:... -
Page 5: Main Power Connection
Main Power Connection Caution! Do not connect fixture to a dimmer system. This unit has Auto switching power supply. It will respond to 110V or 240V automatically This unit must be earthed. (electronically grounded) The occupation of the connection-cable is as follows: This fixture is equipped with an electronic power supply that will let the unit operate from 100V to 240V from 50Hz to 60Hz Cable (USA) Cable (EU) -
Page 6: Main Control Menu
Display Menu CONTROL BOARD MegaLite NovaWW150 Mode Enter Down Address DMX Address Press Set Up to select the DMX start channel use the up/down keys, Press Set Up to confirm the setting Channel Mode DMX Mode This function allows you to select the mode in witch you want to control the fixture. Press Enter use the up/down keys to select desired DMX mode settings. - Page 7 Strobe Mode Strobe This function allows you to select a preprogrammed strobe sequences. Press Enter use the up/down keys to select de- sired strobe program (15 options). Press Enter to set the desired sped use the up/down keys (15 options). Press Enter to confirm the settings.
-
Page 8: Dmx Profile
Nova Lite WW150 DMX Profile Nova Lite WW150 1Ch DMX Channel Function Description Value Dimmer Dimmer Off to Full 0-255 Nova Lite WW150 2Ch DMX Channel Function Description Value Dimmer Dimmer Off to Full 0-255 Strobe (slow to fast) 0-196 Strobe Random Strobe (slow to fast) 197-255... -
Page 9: Cleaning & Maintenance
Pendant Mount: When using pendant and treaded mount consider the following 1) Remove the yoke as it will no longer be used. 2) Using a standard 1/2 bolt you can hang the fixture by thread- ing directly into the top. ( a metric 10mm version is also available part #4450-HPM) 3) Using a steel cable you can hang the fixture by running a steel cable throw the side hole... - Page 10 Customer Support Mega Lite has a customer support line to provide set up help and to answer any question should you encounter a prob- lem. Please visit our website for any other related technical documents. For service related issue please contact our service dept.
